About the product
Kingston's KSM56R46BD8PMI-48MBI is a 6G x 80-bit (48GB) DDR5-5600 CL46 SDRAM (Synchronous DRAM), 2Rx8, ECC, memory module, based on twenty 3G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR5-5600 timing of 46-45-45 at 1.1V. Each 288-pin DIMM uses gold contact fingers.
- Whether you are playing games, using heavy loaded OS or video editing software, the DIMM 48 GB of memory will make them run in a flash
- 5600 MHz of memory speed with Registered signal and CL46 latency allows you to browse web, listen to songs and use routine software simultaneously
- The DDR5 SDRAM efficiently move data across electric components and provide smooth PC performance
Technical Specifications
| Physical Characteristics | |
| Number of Pins | 288-pin |
| Form Factor | DIMM |
| Length | 5.25" (133.35 mm) |
| Width | 1.23" (31.25 mm) |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | Hazard Assessment of Perfluorooctane Sulfonate (PFOS) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Restriction of Hazardous Substances (RoHS) | |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| General Information | |
| Product Type | RAM Module |
| Manufacturer Part Number | KSM56R46BD8PMI-48MBI |
| Manufacturer Website Address | http://www.kingston.com |
| Manufacturer | Kingston Technology Company |
| Product Name | 48GB DDR5 SDRAM Memory Module |
| Brand Name | Kingston |
| Technical Information | |
| CAS Latency | CL46 |
| Error Checking | On-die ECC |
| Signal Processing | Registered |
| Memory Speed | 5600 MHz |
| Memory Size | 48 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Standard | DDR5-5600/PC5-44800 |
| Memory Voltage | 1.10 V |
| Memory Rank | Dual-rank |
