Chief ConnexSys Portrait Video Wall Mount

Name: Chief ConnexSys Portrait Video Wall Mount
Brand: Chief
SKU: AC729514
Price: 1099.52 CAD
Availability: OutOfStock

$1,099.52 CAD

~~$1,231.47 CAD~~ $1,099.52 CAD

-10% OFF Ask for quote

Shipping calculated at checkout.

Chief ConnexSys Portrait Video Wall Mount - For Displays 42-80" - Black - Chief ConnexSys Portrait Video Wall Mount - For Displays 42-80" - Black

VPN:LVS1UP SKU:AC729514 UPC: 91720Z

Supports 80\" displaysCan withstand a maximum weight of 68.04 kg

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

Chief ConnexSys Portrait Video Wall Mount

About the product

Chief's ConnexSys video wall mounting system solves common video wall challenges of speed, alignment, serviceability and rigidity. The ConnexSys video wall mounting system provides the ability to level each row once by using strut channel to connect multiple mounts together with a simple-to-install system that can handle the largest requirements. Hang units on a single strut channel for quick row leveling

There is no need for horizontal spacers and the vertical measurement is simply the height of the display to the next rail. The ConnexSys reduces installation time, especially for XL and recessed configurations with our tool free latching system to secure displays. Power Zone technology provides 6 points of adjustment in one easy-access location at the top of the mount. This mount comes equipped with Rapid Draw Display Release to protect displays by not requiring an aggressive push to release pop-out. The display will release on demand to prevent accidental pop-outs. Tilt adjustment at single pivot point, protects displays from twisting.Supports 80 displaysCan withstand a maximum weight of 68.04 kg

Technical Specifications

Miscellaneous
Additional Information	Compatible with most 1-5/8" sizes of channel strut Reduces installation time - especially for XL and recessed configurations Tool-free ClickConnect latching secures displays PowerZone provides 6 points of adjustment in one easy-to-access location at the top of the mount Height adjustment ±1" on each interface Tilt adjustment at single pivot point, protects displays from twisting Depth can be set between 4" and 7.4" from the wall, providing a range of "home positions" ideal for recessed installations Cord release system gently and remotely pops any screen out for easy access and can be extended 13.4" for service Security - pad lock ¼" shank diameter
Compatibility	TV
Country of Origin	China
Physical Characteristics
Height	32.50" (825.50 mm)
Width	19.50" (495.30 mm)
Depth	4" (101.60 mm)
VESA Mount Compatible	Yes
Product Color	Black
General Information
Product Type	Wall Mount
Manufacturer Part Number	LVS1UP
Manufacturer Website Address	http://www.legrand.com
Manufacturer	Legrand Group
Product Model	LVS1UP
Product Name	Chief ConnexSys Video Wall Mounting System with Rails - For Monitors 42-80"
Brand Name	Chief
Product Information
Device Supported	Flat Panel Display
Features	Adjustable Depth
	Lateral Adjustment
	Tilt
Maximum Load Capacity	150 lb (68038.86 g)
Minimum Screen Size Supported	40" (1016 mm)
Maximum Screen Size Supported	80" (2032 mm)
Maximum Adjustable Depth	13.40" (340.36 mm)
Number of Displays Supported	1
Height Adjustable	Yes
