About the product
- DisplayPort transmits both audio and video signals through a common channel to deliver versatile performance
- Retrieve a significant number of PCI slots, expansion slots, and peripheral ports that have an enhanced heat dissipation capability with the ATX desktop motherboard
- DDR4 SDRAM compatible slot - Allows the memory to operate at an effective bus speed while using minimal power, resulting in an optimal computer performance and improved memory heat dissipation
- Compatible Intel Core i5 processor provides you with the solid performance to watch videos and play games, while its adaptability makes you more productive
Technical Specifications
| Audio | |
| Audio Channels | 5.1 |
| I/O Controller | |
| Controller Type | Serial ATA/600 |
| Video | |
| Onboard Video | CPU Dependent Video |
| Network & Communication | |
| Gigabit Ethernet | Yes |
| 10Gigabit Ethernet | Yes |
| Physical Characteristics | |
| Form Factor | ATX |
| Width | 12" (304.80 mm) |
| Depth | 9.60" (243.84 mm) |
| I/O Expansions | |
| Number of PCI Express x1 Slots | 1 |
| Number of PCI Express x16 Slots | 4 |
| Total Number of PCI Express Slots | 5 |
| Total Number of Expansion Slots | 5 |
| Interfaces/Ports | |
| HDMI | Yes |
| DisplayPort | Yes |
| Total Number of USB Ports | 6 |
| Number of USB 3.2 Ports | 6 |
| Onboard Interfaces | |
| Number of SATA Interfaces | 4 |
| Total Number of Onboard USB Ports | 7 |
| Number of Onboard USB 2.0 Ports | 4 |
| Number of M.2 Interfaces | 3 |
| Number of Onboard USB 3.2 Ports | 3 |
| Memory | |
| Maximum Memory Supported | 128 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Memory Slots | 4 |
| Memory Form Factor | DIMM |
| UDIMM | |
| Memory Speed Supported | 2933 MHz |
| 4000 MHz | |
| General Information | |
| Product Type | Desktop Motherboard |
| Manufacturer Part Number | MBD-C9Z490-PG-O |
| Manufacturer Website Address | http://www.supermicro.com |
| Manufacturer | Supermicro Computer, Inc |
| Product Model | C9Z490-PG |
| Product Name | C9Z490-PG Desktop Motherboard |
| Package Type | Retail |
| Brand Name | Supermicro |
| Processor & Chipset | |
| Processor Supported | Core i7 |
| Core i9 | |
| Celeron | |
| Core i3 | |
| Pentium | |
| Core i5 | |
| Total Processor Supported | 1 |
| Processor Socket | Socket LGA-1200 |
| Chipset Manufacturer | Intel |
| Chipset Model | Z490 |
