About the product
The 10 pack 6ft Mini DisplayPort™ to DisplayPort Adapter Cable, features a Mini DP male connector on one end, and a DP male connector on the other, allowing you to connect any Mini DisplayPort-equipped laptop (including the Mac® family of products) to an HDTV, monitor or projector that uses a standard DisplayPort connection.
The mDP to DP cable supports high resolutions of up to 4k x 2k (3840 x 2160) @ 60Hz with a maximum HBR2 bandwidth of 21.6 Gbps. The cable also supports Multi-Stream (MST) for daisy chaining multiple monitors and provides optional audio support.
This product is backed for life, including free lifetime 24/5 multi-lingual technical assistance.
More from the Manufacturer
- MINI-DP to DISPLAYPORT 1.2 CABLE: This 10 Pack 6ft DisplayPort v1.2 cable supports 4K x 2K (3840x2400p 60Hz, 2560x1600p 120Hz), 21.6 Gbps bandwidth, HBR2, 8Ch Audio, Multi-Stream Transport (MST), GTC for precise audio channel timing & 3D Stereo
- RELIABLE DESIGN: Durable ABS connectors with flexible PVC strain relief & jacket prevents fraying/damage due to bending or rough usage; Metal connector sub-structure provides EMI shielding; Latching DP connectors prevent accidental disconnection
- QUALITY CONSTRUCTION: 32AWG wire with gold-plated connectors for improved signal integrity and reliability; Superior EMI shielding with Al-Mylar foil and copper braid provides higher quality video and audio; Backwards compatible with DP 1.1
- APPLICATIONS: Ideal for home/office/boardroom/classroom works w/laptop (with Mini-DP port)/professional workstations with AMD FirePro W9100/8100, Nvidia NVS 810/510 graphic card; UHD/4K monitor/projector/display; Microsoft Surface Pro 6/4
- SPECS: 6ft (1.8 meters) - Black - DisplayPort v1.2 - Mini-DP Male to Standard DP Latching Male - 32 AWG - PVC cable jacket, ABS connector shell - Shield: Al-Mylar foil with Braid - Protocols: HBR 2, MST, GTC
Technical Specifications
| Miscellaneous | |
| Compatibility |
|
| Country of Origin | Vietnam |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| General Information | |
| Product Type | Video Cable Adapter |
| Manufacturer Part Number | MDP2DPMM610PK |
| Manufacturer Website Address | http://www.startech.com |
| Packaged Quantity | 10 Pack |
| Manufacturer | StarTech.com |
| Product Name | 6 ft (1.8m) Mini DisplayPort to DisplayPort Cable - M/M |
| Brand Name | StarTech.com |
| Physical Characteristics | |
| Shipping Weight (Approximate) | 1.61 lb (730.28 g) |
| Weight (Approximate) | 2.43 oz (69 g) |
| Shipping Height | 0.60" (15.24 mm) |
| Shipping Width | 14.10" (358.14 mm) |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Shielding Material | Braided Copper |
| Aluminum Mylar Foil | |
| Product Color | Black |
| Color Family | Black |
| Connector Material | ABS |
| Metal | |
| Technical Information | |
| Cable Length | 6.6 ft (2 m) |
| Data Transfer Rate | 21.6 Gbit/s |
| Device Supported | HDTV |
| Audio/Video Device | |
| Monitor | |
| Graphic Card | |
| Projector | |
| Tablet PC | |
| Workstation | |
| Notebook | |
| Jacket Type | CMG |
| Shielding | Yes |
| Features | Flexible |
| Bendable | |
| Multi-Stream Transport (MST) Support | |
| Latching Connector | |
| Fray Resistant | |
| Strain Relief | |
| EMI Protection | |
| Damage Resistant | |
| Number of Conductors | 19 |
| Cable Type | DisplayPort/Mini DisplayPort |
| Connector Type on First End | DisplayPort 1.2 Digital Audio/Video - Male |
| Connector Type on Second End | Mini DisplayPort 1.2 Digital Audio/Video - Male |
| Connector Plating | Gold |
| American Wire Gauge | 32 AWG |
| Supported Resolution | 3840 x 2400 |
| Connector on First End Details | 1 x DisplayPort 1.2 Digital Audio/Video - Male |
| Connector on Second End Details | 1 x Mini DisplayPort 1.2 Digital Audio/Video - Male |
| Connector Gender on First End | Male |
| Connector Gender on Second End | Male |
