About the product
- Universal AC input/Full range
- Protections: Short circuit / Overload / Over voltage
- Cooling by free air convection
- Can be installed on DIN rail TS-35/7.5 or 15
- Built in DC OK active signal
- LED indicator for power on
- No load power consumption<0.75W
- 100% full load burn-in test
- 3 years warranty
Technical Specifications
| Reliability | |
| MTBF | 2780800 Hour |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Taiwan Restriction of Hazardous Substances (Taiwan RoHS) |
| Restriction of Hazardous Substances (RoHS) | |
| Physical Characteristics | |
| Weight (Approximate) | 190 g |
| Form Factor | DIN Rail |
| Height | 3.54" (90 mm) |
| Width | 0.89" (22.50 mm) |
| Depth | 3.94" (100 mm) |
| Technical Information | |
| Efficiency | 76% |
| Features | LED indicator |
| Protection Type | Over Voltage |
| Overload | |
| Short Circuit | |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Output Power | 15 W |
| Output Voltage | 5 V DC |
| Output Current | 3 A |
| Input Frequency | 63Hz |
| Output Voltage Detail | 5 V DC @ 3 A |
| General Information | |
| Product Type | Power Supply |
| Manufacturer Part Number | MDR205 |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | MDR-20-5 |
| Product Name | 20W Single Output Industrial DIN Rail Power Supply |
| Product Line | MeanWell |
| Product Series | MDR-20 |
| Brand Name | Advantech |
