About the product
The Vertiv Liebert MP2-220L Micropod maintenance bypass and Power Output Distribution (POD) switch allows you to manually transfer the connected equipment to utility power via a maintenance bypass switch, permitting scheduled maintenance or UPS replacement without discontinuing power to the critical load. it is designed for Liebert GXT5-2000IRT2UXL and GXT5-3000IRT2UXL.
Technical Specifications
| Technical Information | |
| Plug/Connector Type | IEC 60320 C20 |
| Miscellaneous | |
| Compatibility | Liebert GXT5, GXT RT+, Edge UPS |
| Certifications & Standards | CE Marked |
| Power Description | |
| Input Voltage | 230 V AC |
| Current | 16 A |
| 10 A | |
| Load Capacity (VA) | 3 kW |
| General Information | |
| Product Type | Bypass Switch |
| Manufacturer Part Number | MP2-220L |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Manufacturer | Vertiv |
| Product Name | MicroPOD External Maintenance Bypass Switch |
| Product Line | MicroPOD |
| Brand Name | Vertiv Liebert |
| Physical Characteristics | |
| Weight (Approximate) | 4.41 lb (2000 g) |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.46" (88 mm) |
| Width | 15.51" (394 mm) |
| Depth | 3.03" (77 mm) |
| Product Color | Black |
| Color Family | Black |
