About the product
Features | SFP+ Transceiver for Connecting Copper Cabling to Your Cisco Network Switch or Router
This SFP+ transceiver allows you to connect a copper Cat6a cable to a 1/2.5/5/10 Gbps fiber network router, server or switch. It transmits data up to 98 feet (30 meters) and supports bi-directional Gigabit Ethernet communication up to 10 Gbps.
Functionally Equivalent to Cisco SFP-10G-T-X Transceiver Module
The MSA-compliant N286-10G-TC functions just like the equivalent Cisco SFP-10G-T-X transceiver module and is manufactured to meet or exceed Cisco specifications. You can use this transceiver with any compatible Cisco router, server or switch and receive the same performance as the SFP-10G-T-X.
Hot-Swappable for Installation Without Network Interruption
This input/output device is fully hot-swappable, so you can install it without a potentially costly 1G/2.5G/5G/10G network shutdown or device reboot. Just plug the SFP end of the transceiver into your Cisco network device. The other end has an RJ45 connector to link with high-speed Cat6a patch cable (sold separately). A convenient bail clasp latch helps you carefully remove the module from the device.
Premium Features for Superior Performance
The auto-sensing RJ45 port supports auto-negotiation and automatic MDI/MDI-X crossover to match the other end of the connection. The zinc housing protects against electromagnetic interference (EMI) and excessive power dissipation.
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Supports twisted pair cables for durability and improved signal transfer while ensuring smooth and seamless data transfer
- Optimize the network's performance with 10 Gigabit Ethernet connectivity
- Enjoy flexibility and scalability with data transfer rate of up to 10 Gbps with 10 Gigabit Ethernet technology
- With 10GBase-T technology, enjoy up to 10Gbps data transfer rate over twisted pair cable
Technical Specifications
| Technical Information | |
| Application/Usage | Data Networking |
| Interfaces/Ports | |
| Interfaces/Ports Details | 1 x RJ-45 10GBase-T Network LAN |
| Connector Type | RJ-45 |
| Total Number of Ports | 1 |
| Miscellaneous | |
| Compatibility |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Restriction of Hazardous Substances (RoHS) | |
| Physical Characteristics | |
| Form Factor | Hot-swappable |
| Height | 0.33" (8.38 mm) |
| Width | 0.53" (13.46 mm) |
| Depth | 2.68" (68.07 mm) |
| Media & Performance | |
| Maximum Distance Supported | 0.03 km (0.02 Mile) |
| Network Technology | 10GBase-T |
| Twisted Pair Cable Standard | Category 6a |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Ethernet Technology | 10 Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| General Information | |
| Product Type | SFP+ |
| Manufacturer Part Number | N28610GTC |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Manufacturer | Eaton Corporation |
| Product Model | N286-10G-TC |
| Product Name | Cisco N286-10G-TC SFP+ Module |
| Brand Name | Tripp Lite by Eaton |
