NEXUS 9400 CPU CARD WITH PTP SYNCE

Name: NEXUS 9400 CPU CARD WITH PTP SYNCE
Brand: Cisco
SKU: 106860NDN
Price: 16623.96 CAD
Availability: OutOfStock

$16,623.96 CAD

~~$18,618.84 CAD~~ $16,623.96 CAD

-10% OFF Ask for quote

Shipping calculated at checkout.

Cisco Nexus 9400 CPU card with PTP, SyncE - For Data Networking, Optical Network - 1 x console - RJ-45, 1 x ToD timing port - RJ-45, 1 x 1000Base-T (management) - RJ-45 - Optical Fiber, Twisted Pair10 Gigabit Ethernet, Gigabit Ethernet - 1000Base-T, 10GBase-X - 3 x Expansion Slots - SFP, SFP+ - Plug-in Module

VPN:N9K-C9400-SUP-A SKU:106860NDN UPC:

Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances
Optical fiber cable compatible - Spans afar and provides speedy data transmission rates between servers and network components
Enjoy flexibility and scalability with data transfer rate of up to 10 Gbps with 10 Gigabit Ethernet technology

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

About the product

Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances
Optical fiber cable compatible - Spans afar and provides speedy data transmission rates between servers and network components
Enjoy flexibility and scalability with data transfer rate of up to 10 Gbps with 10 Gigabit Ethernet technology
With 1000Base-T technology, get up to 1000Mbps data transfer rate over twisted pair cable

Technical Specifications

Miscellaneous
Compatibility	Cisco Nexus 9400 Series Switches
Technical Information
Application/Usage	Data Networking
	Optical Network
I/O Expansions
Expansion Slot Type	SFP+
	SFP
Total Number of Expansion Slots	3
Physical Characteristics
Weight (Approximate)	2.65 lb (1200 g)
Form Factor	Plug-in Module
Height	6.73" (170.94 mm)
Width	1.16" (29.46 mm)
Depth	9.45" (240.03 mm)
Interfaces/Ports
Interfaces/Ports Details	1 x console - RJ-45
	1 x 1000Base-T (management) - RJ-45
	1 x ToD timing port - RJ-45
Connector Type	USB 3.0
	RJ-45
Total Number of Ports	3
Media & Performance
Network Technology	10GBase-X
	1000Base-T
Ethernet Technology	Gigabit Ethernet
	10 Gigabit Ethernet
Media Type Supported	Optical Fiber
	Twisted Pair
General Information
Product Type	Expansion Module
Manufacturer Part Number	N9KC9400SUPA
Manufacturer Website Address	http://www.cisco.com
Manufacturer	Cisco Systems, Inc
Product Model	N9K-C9400-SUP-A
Product Name	Nexus 9400 CPU card with PTP, SyncE
Brand Name	Cisco
