About the product
Uniview UNV 8 Channel NVR with UMD, 8 PoE Ports.
Visit Aartech's Uniview Resource Page for selection guides, design tools, accessories guides, support information and more.
BEST WARRANTY
Uniview UNV DVRs and NVRs purchased through Aartech Canada come with a 3 year exchange warranty. Advanced replacement available for Aartech gold and platinum dealers. Warranty and return details may be found here.
Uniview UNV 8 Channel NVR Features
- Support Ultra265/H.265 video formats
- 4/8-channel input
- Plug & Play with 4/8 independent PoE network interfaces
- Support mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols
- Support HDMI and VGA simultaneous output
- Up to 8 Megapixels resolution recording
- 1 SATA HDD, up to 8TB for each HDD
- ANR technology enhances storage reliability when the network is disconnected
- Support cloud upgrade
Uniview UNV 8 Channel NVR Specifications
- Video/Audio Input:
- IP Video Input: 8-ch
- Audio Input: 1-ch, RCA
- Network:
- Incoming Bandwidth: 80Mbps
- Outgoing Bandwidth: 64Mbps
- Remote Users: 128
- Protocols: TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP
- Browser:
- IE(IE10/11) for Windows
- Firefox (version 52.0 and above) for Windows
- Chrome(version 45 and above) for Windows
- Edge(version 79 and above) for Windows
- Video/Audio Output:
- HDMI/VGA Output:
- HDMI: 4K (3840x2160)@30, 1920x1080p@60, 1920x1080p@50, 1600x1200@60, 1280x1024@60, 1280x720@60, 1024x768@60
- VGA: 1920x1080p@60, 1920x1080p@50, 1280x1024@60, 1600x1200@60, 1280x720@60, 1024x768@60
- Recording Resolution: 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
- Audio Output: 1-ch, RCA
- Two-way Audio: 1-ch, RCA(Using the audio input and output)
- Audio Compression: G.711A, G.711U
- Synchronous Playback: 8-ch
- Liveview display: 1/4/6/8/9
- Corridor Mode Screen: 3/4/5/7/9
- HDMI/VGA Output:
- Snapshot:
- FTP/Schedule/Event Snapshot: 4-ch snapshot, up to D1 resolution
- Decoding:
- Decoding format: Ultra 265/H.265
- Live view/Playback: 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
- Capability: 4 x 4K@30, 6 x 5MP@30, 8 x 4MP@30, 9 x 4MP@25, 10 x 3MP@30, 16 x 1080p@30
- Hard Disk:
- SATA: 1 SATA interfaces
- Capacity: Up to 8TB for each disk (The maximum HDD capacity varies with environment temperature)
- Smart:
- VCA Detection by Camera: Face Detection, Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, SMD(Smart Motion Detection)
- VCA Search: Face Search, Behavior Search, People Counting Report
- People counting: People Flow Counting, Crowd Density Monitoring
- Smart Intrusion Prevention (SIP), Face Detection, SMD by Camera: Total 4-ch
- General Alarm:
- General Alarm: Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection
- Alert Alarm: IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal
- External Interface:
- Network Interface: 1 RJ-45 10M/100M self-adaptive Ethernet Interface
- USB Interface:
- Front panel: 1 x USB2.0
- Rear panel: 1 x USB3.0
- RS232: NA
- RS485: NA
- Alarm In: NA
- Alarm Out: NA
- PoE:
- Interface: 8 RJ-45 10M/100M self-adaptive Ethernet Interface
- Max Power:
- Max 30W for single port
- Max 75W in total
- Supported Standard: IEEE 802.3af/at
- General:
- Power Supply:
- 52V DC/1.8A
- Power Consumption: ? 10W (without HDD)
- Working Environment: -10°C~+ 55°C (+14°F~+131°F), Humidity ? 90% RH (non-condensing)
- Dimensions (W×D×H): 260mm × 222mm × 47mm (10.2"" × 8.7"" × 1.8"")
- Weight (without HDD): ? 0.98Kg (2.16lb)
- Power Supply:
- Certification:
- Certification: CE, FCC, UL, RoHS, WEEE
- CE: EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017
- FCC: Part15 Subpart B, ANSI C63.4
Technical Specifications
Uniview UNV 8 Channel NVR with UMD, 8 PoE Ports.
Visit Aartech's Uniview Resource Page for selection guides, design tools, accessories guides, support information and more.
BEST WARRANTY
Uniview UNV DVRs and NVRs purchased through Aartech Canada come with a 3 year exchange warranty. Advanced replacement available for Aartech gold and platinum dealers. Warranty and return details may be found here.
Uniview UNV 8 Channel NVR Features
- Support Ultra265/H.265 video formats
- 4/8-channel input
- Plug & Play with 4/8 independent PoE network interfaces
- Support mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols
- Support HDMI and VGA simultaneous output
- Up to 8 Megapixels resolution recording
- 1 SATA HDD, up to 8TB for each HDD
- ANR technology enhances storage reliability when the network is disconnected
- Support cloud upgrade
Uniview UNV 8 Channel NVR Specifications
- Video/Audio Input:
- IP Video Input: 8-ch
- Audio Input: 1-ch, RCA
- Network:
- Incoming Bandwidth: 80Mbps
- Outgoing Bandwidth: 64Mbps
- Remote Users: 128
- Protocols: TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP
- Browser:
- IE(IE10/11) for Windows
- Firefox (version 52.0 and above) for Windows
- Chrome(version 45 and above) for Windows
- Edge(version 79 and above) for Windows
- Video/Audio Output:
- HDMI/VGA Output:
- HDMI: 4K (3840x2160)@30, 1920x1080p@60, 1920x1080p@50, 1600x1200@60, 1280x1024@60, 1280x720@60, 1024x768@60
- VGA: 1920x1080p@60, 1920x1080p@50, 1280x1024@60, 1600x1200@60, 1280x720@60, 1024x768@60
- Recording Resolution: 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
- Audio Output: 1-ch, RCA
- Two-way Audio: 1-ch, RCA(Using the audio input and output)
- Audio Compression: G.711A, G.711U
- Synchronous Playback: 8-ch
- Liveview display: 1/4/6/8/9
- Corridor Mode Screen: 3/4/5/7/9
- HDMI/VGA Output:
- Snapshot:
- FTP/Schedule/Event Snapshot: 4-ch snapshot, up to D1 resolution
- Decoding:
- Decoding format: Ultra 265/H.265
- Live view/Playback: 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
- Capability: 4 x 4K@30, 6 x 5MP@30, 8 x 4MP@30, 9 x 4MP@25, 10 x 3MP@30, 16 x 1080p@30
- Hard Disk:
- SATA: 1 SATA interfaces
- Capacity: Up to 8TB for each disk (The maximum HDD capacity varies with environment temperature)
- Smart:
- VCA Detection by Camera: Face Detection, Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, SMD(Smart Motion Detection)
- VCA Search: Face Search, Behavior Search, People Counting Report
- People counting: People Flow Counting, Crowd Density Monitoring
- Smart Intrusion Prevention (SIP), Face Detection, SMD by Camera: Total 4-ch
- General Alarm:
- General Alarm: Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection
- Alert Alarm: IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal
- External Interface:
- Network Interface: 1 RJ-45 10M/100M self-adaptive Ethernet Interface
- USB Interface:
- Front panel: 1 x USB2.0
- Rear panel: 1 x USB3.0
- RS232: NA
- RS485: NA
- Alarm In: NA
- Alarm Out: NA
- PoE:
- Interface: 8 RJ-45 10M/100M self-adaptive Ethernet Interface
- Max Power:
- Max 30W for single port
- Max 75W in total
- Supported Standard: IEEE 802.3af/at
- General:
- Power Supply:
- 52V DC/1.8A
- Power Consumption: ? 10W (without HDD)
- Working Environment: -10°C~+ 55°C (+14°F~+131°F), Humidity ? 90% RH (non-condensing)
- Dimensions (W×D×H): 260mm × 222mm × 47mm (10.2"" × 8.7"" × 1.8"")
- Weight (without HDD): ? 0.98Kg (2.16lb)
- Power Supply:
- Certification:
- Certification: CE, FCC, UL, RoHS, WEEE
- CE: EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017
- FCC: Part15 Subpart B, ANSI C63.4
