About the product
Designed to put the power of choice in your hands, the OWC Mercury Elite Pro Quad packs an unprecedented combination of USB connectivity, universal drive bays, and advanced SoftRAID capabilities into a whisper-quiet aluminum enclosure. Whatever your workflow needs, the Mercury Elite Pro Quad has the flexibility to take your storage capacity, performance, and data security to a whole new level.
The Flexibility of USB-C
The Mercury Elite Pro Quad's powerful USB-C interface delivers USB 3.2 (10Gb/s) bandwidth and works with any USB-C or Thunderbolt 3 equipped Mac or Windows PC. Simply connect the Mercury Elite Pro Quad via the included USB-C cable to experience next-level performance. If your computer doesn't feature USB-C connectivity, the included USB-C to USB-A cable brings backward compatibility for machines with legacy USB ports.
Capacity without Compromise
Compatible with 2.5" and 3.5" drives, the Mercury Elite Pro Quad's four universal drive bays provide users massive storage possibilities. With this level of capacity and drive flexibility, you will not have to compromise when it comes to your storage.
The Most Powerful RAID Tool on the Planet.
SoftRAID is the world's fastest and most flexible application to configure, maintain, and protect your RAID volumes on Mac and PC. OWC enclosures include 3 Years of SoftRAID Premium.
- High-Performance RAID 0/1/4/5/1+0 (10) volumes
- Predictive Health Monitoring proactively notifies of Volume and Disk issues well before failure - provided on your computer and remotely
- 35+ Years of Experience of Pro Support to provide peace-of-mind with setup help, ongoing questions, or urgent disk issues
- And many more unique features.
- No need to learn how to install internally, it can be mounted externally
- Featuring Non-RAID Mode - Data reliability, fault tolerance, and enhanced performance through jbod
- Compact in size but massive in performance. Provides sufficient external data storage, with ultra-fast data transfer speeds and configurable modes.
Technical Specifications
| Controllers | |
| Non-RAID Mode | JBOD |
| Software RAID Supported | Yes |
| Miscellaneous | |
| Package Contents |
|
| Compatibility |
|
| I/O Expansions | |
| Number of Total Expansion Bays | 4 |
| "Number of 2.5""/3.5"" Bays" | 4 |
| Hot Swappable Bays | Yes |
| Interfaces/Ports | |
| Host Interface | USB 3.2 (Gen 2) Type C |
| Number of USB Ports | 1 |
| Drive Interface | SATA |
| Technical Information | |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Total Hard Drive Capacity Installed | 96 TB |
| Number of Hard Drives Supported | 4 |
| Number of Hard Drives Installed | 4 |
| Number of Solid State Drive Supported | 4 |
| Physical Characteristics | |
| Weight (Approximate) | 13.89 lb (6300 g) |
| Form Factor | External |
| Height | 7.30" (185.42 mm) |
| Width | 5.30" (134.62 mm) |
| Depth | 9.40" (238.76 mm) |
| Cooling Fan | Yes |
| Product Material | Aluminum |
| General Information | |
| Product Type | Drive Enclosure |
| Manufacturer Part Number | OWCMEQCTSRT96 |
| Manufacturer Website Address | https://www.owc.com/ |
| Packaged Quantity | 1 |
| Manufacturer | Other World Computing |
| Product Name | Mercury Elite Pro Quad External Storage Solution |
| Product Line | Mercury Elite Pro Quad |
| Brand Name | OWC |
| Software | |
| Operating System Supported | Windows Server 2016 |
| Windows Server 2019 | |
| Windows Server 2022 | |
| Windows 7 | |
| Windows 7 x64 | |
| Windows 8 | |
| Windows 8 x64 | |
| Windows 8.1 | |
| Windows 8.1 x64 | |
| Windows Home Server 2011 | |
| Mac OS X 10.13 High Sierra | |
| Mac OS X 10.14 Mojave | |
| Mac OS X 10.15 Catalina | |
| Mac OS X 10.6 Snow Leopard | |
| Mac OS X 10.7 Lion | |
| Mac OS X 10.8 Mountain Lion | |
| Mac OS X 10.9 Mavericks | |
| Mac OS X 11.x Big Sur | |
| Mac OS X 12.x Monterey | |
| Mac OS X 13.x Ventura | |
| Mac OS X 14.x Sonoma | |
| macOS Sequoia 15.x | |
| Windows 10 | |
| Windows 10 x64 | |
| Windows 11 | |
| Mac OS X 10.10 Yosemite | |
| Mac OS X 10.11 El Capitan | |
| Mac OS X 10.12 Sierra | |
| Windows Server 2012 |
