About the product
The P134-06N-DVI-DL DisplayPort to DVI Dual-Link Active Converter (M/F) connects a DisplayPort computer to the DVI-I dual-link port on a monitor, projector or television. With a male DisplayPort connector and a female DVI dual-link connector, this video adapter lets you use your existing DVI display and DVI cable instead of buying a new DisplayPort monitor.
Ideal for displaying video on a large monitor or digital sign, this active converter supports DVI dual-link video resolutions up to 2560 x 1600 and DVI single-link video resolutions up to 1920 x 1080 (1080p). Because it's an active converter, the P134-06N-DVI-DL converts both Multi-Mode (DP++) and Single-Mode DisplayPort output. It's recommended for use with graphics cards, such as AMD Eyefinity, that do not output DP++ signals.
Plug and play with no software, drivers or power supply needed. The unit is powered by connecting its built-in USB cable to the DisplayPort device. Gold-plated connectors and contacts ensure excellent conductivity. Integral strain relief ensures the converter and molded connectors last a long time. The P134-06N-DVI-DL fits easily in a briefcase, backpack or laptop bag for connecting on the go.
Ideal for displaying video on a large monitor or digital sign, this active converter supports DVI dual-link video resolutions up to 2560 x 1600 and DVI single-link video resolutions up to 1920 x 1080 (1080p). Because it's an active converter, the P134-06N-DVI-DL converts both Multi-Mode (DP++) and Single-Mode DisplayPort output. It's recommended for use with graphics cards, such as AMD Eyefinity, that do not output DP++ signals.
Plug and play with no software, drivers or power supply needed. The unit is powered by connecting its built-in USB cable to the DisplayPort device. Gold-plated connectors and contacts ensure excellent conductivity. Integral strain relief ensures the converter and molded connectors last a long time. The P134-06N-DVI-DL fits easily in a briefcase, backpack or laptop bag for connecting on the go.
Send High-Definition DisplayPort Video Signals to a DVI Display
- Connects DisplayPort computer to DVI-D dual-link monitor, projector or TV
- Active converter works with all DisplayPort signals
- Ideal for displaying video on large monitor or digital sign
- Female DVI dual-link and male DisplayPort connectors
Vibrant, Superior Video Quality
- Supports DVI dual-link video resolutions up to 2560 x 1600
- Supports DVI single-link video resolutions up to 1920 x 1080 (1080p)
- Supports 24-bit Deep Color (8 bits per channel)
- Converts Multi-Mode (DP++) and Single-Mode DisplayPort output
- Works with graphics cards that don't output DP++ signals, such as AMD Eyefinity
Superior Materials for Superior Performance
- Gold-plated connectors and contacts for excellent conductivity
- Integral strain relief for long life
- Plug-and-play-no software, drivers or power supply necessary
- Fits easily into briefcase, backpack or laptop bag
- Features Active
- Lets you enjoy HD quality movies
- With USB port, enjoy the plug-and-play facility
- Fully compatible with TVs
Technical Specifications
| Miscellaneous | |
| Country of Origin | Vietnam |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Shipping Weight (Approximate) | 5.60 oz (158.76 g) |
| Shipping Height | 1.30" (33.02 mm) |
| Shipping Width | 3.50" (88.90 mm) |
| Product Color | Silver |
| Color Family | Silver |
| General Information | |
| Product Type | Video Cable |
| Manufacturer Part Number | P134-06N-DVI-DL |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Manufacturer | Eaton Corporation |
| Product Model | P134-06N-DVI-DL |
| Product Name | P134-06N-DVI-DL DisplayPort to DVI Dual-Link Active Converter (M/F), 6 in |
| Brand Name | Tripp Lite series |
| Technical Information | |
| Cable Length | 6" (152.40 mm) |
| Device Supported | Graphics Card |
| Monitor | |
| Notebook | |
| Projector | |
| Video Device | |
| TV | |
| Features | Molded |
| Strain Relief | |
| Active | |
| Cable Type | DisplayPort/DVI/USB |
| Connector Type on First End | DisplayPort Digital Audio/Video - Male |
| USB Type A - Male | |
| Connector Type on Second End | DVI-D (Dual-Link) Digital Video - Female |
| Connector Plating | Gold |
| Supported Resolution | 2560 x 1600 |
| Contact Plating | Gold |
| Connector on First End Details | 1 x USB Type A - Male |
| 1 x DisplayPort Digital Audio/Video - Male | |
| Connector on Second End Details | 1 x DVI-D (Dual-Link) Digital Video - Female |
