About the product
- PDU allows power to be more efficiently distributed and controlled
- Before critical input source become overloaded always be warned with monitored PDUs
Technical Specifications
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Management | |
| Management |
|
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Restriction of Hazardous Substances (RoHS) | |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Input Current | 30 A |
| Input Voltage Range | 100 V AC - 240 V AC |
| Power Rating (VA) | 8.60 kVA |
| Power Rating (Watt) | 8.60 kW |
| Technical Information | |
| Plug/Connector Type | NEMA L21-30P |
| Phase | Three Phase |
| Receptacle Type | IEC 60320 C19 |
| IEC 60320 C13 | |
| PDU Type | Monitored |
| Receptacle Detail | 6 x IEC 60320 C19 |
| 30 x IEC 60320 C13 | |
| Physical Characteristics | |
| Mount Type | Rack-mountable |
| Rack Height | 0U |
| Height | 68.90" (1750.10 mm) |
| Width | 2" (50.80 mm) |
| Depth | 2.10" (53.30 mm) |
| Mounting Orientation | Vertical |
| Product Color | Blue |
| Color Family | Blue |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | P36G19M-BU1C |
| Manufacturer Website Address | http://www.panduit.com |
| Packaged Quantity | 1 |
| Manufacturer | PANDUIT CORP |
| Product Name | SmartZone MI 36-Outlets PDU |
| Product Line | SmartZone |
| Product Series | MI |
| Brand Name | Panduit |
