About the product
The dense and compact HPE ProLiant DL20 Gen10 Plus server powered by Intel® Xeon® E and Pentium® Processors provides a unique blend of enterprise class capabilities & value. It offers outstanding configuration flexibility to cater to a wide variety of business requirements at an affordable price point. Deploy this dense platform for diverse workloads in space constrained environments and maintain it with ease by automating the most essential server lifecycle management tasks with HPE iLO 5.
- Gigabit Ethernet port for ultra-fast network speeds
- 1 x 500 W power supply unit (PSU) for your system's power requirements
- Experience high performance, built-in security and remote management capabilities with Intel Xeon 2.80 GHz processor
- With 16 GB memory, improve system performance to execute complex applications
Technical Specifications
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C256 |
| Controllers | |
| Controller Type | Serial ATA |
| Controller Model | Intel VROC |
| Display & Graphics | |
| Graphics Controller Model | G200 |
| Graphics Memory Capacity | 16 MB |
| Miscellaneous | |
| Security Features |
|
| Energy Star | Yes |
| Storage | |
| Optical Drive Type | No |
| Number of Hard Drives | No |
| Power Description | |
| Plug/Connector Type | C13/C14 |
| Number of Power Supplies Supported | 1 |
| Number of Power Supplies Installed | 1 |
| Hot Swappable Power Supply | Yes |
| Maximum Power Supply Wattage | 500 W |
| Physical Characteristics | |
| Weight (Approximate) | 20.86 lb (9460 g) |
| Form Factor | Rack |
| Rack Height | 1U |
| Height | 1.70" (43.20 mm) |
| Width | 17.11" (434.60 mm) |
| Depth | 15.05" (382.20 mm) |
| I/O Expansions | |
| "Number of External 5.25"" Bays" | 1 |
| "Number of Internal 2.5"" Bays" | 4 |
| Number of Total Expansion Bays | 5 |
| Total Number of Expansion Slots | 2 |
| Hot Swappable Bays | Yes |
| Number of SFF Bays | 4 |
| PCI Express Details | 2 PCIe 4.0 slots |
| Interfaces/Ports | |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Remote Management | Yes |
| Total Number of USB Ports | 5 |
| Number of VGA Ports | 1 |
| Remote Management Controller | iLO Management (standard), Intelligent Provisioning (standard) |
| Memory | |
| Error Checking | ECC |
| Maximum Memory Supported | 128 GB |
| Signal Processing | Unregistered (Unbuffered) |
| Standard Memory | 16 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Occupied Memory Slots | 1 |
| Total Number of Memory Slots | 4 |
| Processor | |
| Cache | 8 MB |
| Processor Speed | 2.80 GHz |
| Processor Type | Xeon |
| Processor Model | E-2314 |
| Processor Core | Quad-core (4 Core) |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| General Information | |
| Product Type | Server |
| Manufacturer Part Number | P44114-B21 |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | ProLiant DL20 Gen10 Plus E-2314 2.8GHz 4-core 1P 16GB-U 4SFF 500W RPS Server |
| Product Line | ProLiant |
| Product Series | DL20 G10 Plus |
| Brand Name | HPE |
| Operating System | |
| Operating System | No |
| Operating System Supported | SUSE Linux Enterprise Server 12 |
| SUSE Linux Enterprise Server 12 SP5 | |
| SuSE Linux Enterprise Server 15 | |
| SUSE Linux Enterprise Server 15 SP3 | |
| Windows Server 2019 | |
| Windows Server 2019 Datacenter | |
| Windows Server 2019 Essentials | |
| Windows Server 2019 Standard | |
| Windows Server 2022 | |
| Windows Server 2022 Datacenter | |
| Windows Server 2022 Essentials | |
| Windows Server 2022 Standard | |
| Hyper-V | |
| Red Hat Enterprise Linux 8.4 |
