Switches Devices
Expected delivery 3 to 7 business days (exceptions applied)
Startech
4-PORT DP KVM SWITCH 4K 60HZ DISPLAYPORT TAA COMPLIANT
4-PORT DP KVM SWITCH 4K 60HZ DISPLAYPORT TAA COMPLIANT
VPNP4AD122-KVM-SWITCH SKU:836120DIS UPC:65030908436
- FAST SWITCHING 4K 60HZ KVM: Control up to four DisplayPort-enabled desktops/workstations/servers from one mouse, keyboard, USB 5Gbps hub, and 4K 60Hz DisplayPort monitor; Ideal for CAD/CAM, video editing, and content creation applications
- MULTIPLE SWITCHING OPTIONS: Fast Switching via push-buttons or hotkeys with an audible buzzer providing confirmation; LEDs provide quick visual port selection status; Listen to audio from one computer while controlling another
- UNIVERSAL COMPATIBILITY: TAA-Compliant KVM Switch provides BIOS/UEFI control and works with any operating system including Windows, macOS, ChromeOS, and Linux; No software required; Compatible with all hardware platforms such as Intel, AMD, and Apple
Couldn't load pickup availability
Volume discount available - Ask for quote..
View full details





Recently Viewed
4-PORT DP KVM SWITCH 4K 60HZ DISPLAYPORT TAA COMPLIANT
Product information summary

About the product
This DisplayPort KVM Switch enables users to switch between two desktops equipped with USB-A and DisplayPort. It facilitates sharing a 4K 60Hz DisplayPort monitor, a keyboard, mouse, two USB 5Gbps devices, a stereo audio output device, and four USB 2.0 devices.
High-Resolution 4K 60Hz Video
This KVM supports resolutions up to 4K 60Hz, making it ideal for applications such as CAD/CAM, video editing, and content creation. In addition, its support for High Dynamic Range (HDR) enhances contrast, brightness, color, and overall vibrancy.
Customizable Switching
This universal KVM switch offers hotkey and push-button switching. Hotkeys allow independent switching of audio and video, enabling audio playback from one computer while controlling another. An audible buzzer confirms hotkey inputs, and LEDs provide visual status feedback for the selected host.
Universal Compatibility
The TAA-compliant KVM Switch offers universal compatibility and works with all operating systems, including Windows, macOS, ChromeOS, and Linux. It is also compatible with all hardware platforms, including Intel and AMD.
Reliable Performance
The rugged metal case helps prevent electromagnetic interference (EMI). 8kV Air/6kV Contact ESD protection enhances the reliability and longevity of the KVM. The included set of rubber feet protect the work surface from scratches and keep KVM in place during operation.
- FAST SWITCHING 4K 60HZ KVM: Control up to four DisplayPort-enabled desktops/workstations/servers from one mouse, keyboard, USB 5Gbps hub, and 4K 60Hz DisplayPort monitor; Ideal for CAD/CAM, video editing, and content creation applications
- MULTIPLE SWITCHING OPTIONS: Fast Switching via push-buttons or hotkeys with an audible buzzer providing confirmation; LEDs provide quick visual port selection status; Listen to audio from one computer while controlling another
- UNIVERSAL COMPATIBILITY: TAA-Compliant KVM Switch provides BIOS/UEFI control and works with any operating system including Windows, macOS, ChromeOS, and Linux; No software required; Compatible with all hardware platforms such as Intel, AMD, and Apple
- DURABLE DESIGN: Metal housing helps prevent Electro-magnetic Interference (EMI); 8kV Air/6kV Contact ESD protection enhances the reliability and longevity of the KVM; Included rubber feet protect the work surface and keep KVM in place during operation
- TECHNICAL SPECIFICATIONS: KVM Switch is DisplayPort 1.2 compliant, supporting resolutions up to 4K 60Hz, HDR10, and HDCP 1.4; Supports DisplayPort Audio and 3.5mm analog audio; 4x USB HID Ports; 2x USB 5Gbps Hub Ports; OS Independent
Technical Specifications
Environmental Conditions | |
Minimum Operating Temperature | 32°F (0°C) |
Maximum Operating Temperature | 104°F (40°C) |
Video | |
Maximum Video Resolution | 4096 x 2160 |
Graphic Mode | 4K |
Power Description | |
Frequency | 60 Hz |
Input Current | 1 A |
Power Plug Type | Type M |
Miscellaneous | |
Package Contents |
|
TAA Compliant | Yes |
Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
Restriction of Hazardous Substances (RoHS) | |
Physical Characteristics | |
Weight (Approximate) | 2.30 lb (1043.262451 g) |
Form Factor | Desktop |
Length | 8.70" (220.98 mm) |
Height | 1.70" (43.18 mm) |
Width | 5.10" (129.54 mm) |
Technical Information | |
Features | LED Indicator |
Maximum Data Transfer Rate | 640 MB/s |
KVM Technology | Digital & Analog |
Number of Computers Supported | 4 |
Device Type | Desktop KVM |
General Information | |
Product Type | KVM Switchbox |
Manufacturer Part Number | P4AD122-KVM-SWITCH |
Manufacturer Website Address | http://www.startech.com |
Packaged Quantity | 1 |
Manufacturer | StarTech.com |
Product Name | KVM Switchbox |
Brand Name | StarTech.com |
Interfaces/Ports | |
USB | Yes |
Number of USB Ports | 6 |
DisplayPort | Yes |
USB Standard | USB 3.2 |
USB 2.0 | |
Number of DisplayPorts | 5 |
USB 2.0 | Yes |
