About the product
Does your data center need a secure, performance driven dense server that you can confidently deploy for virtualization, database, or high-performance computing? The HPE ProLiant DL360 Gen10 server delivers security, agility and flexibility without compromise.
The HPE ProLiant DL360 Gen10 Server supports the Intel® Xeon® Scalable Processor Family with up to 28 cores, plus 2933 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB max. With the added performance that HPE Persistent Memory and 10 NVMe bring, the HPE ProLiant DL360 Gen10 means business. Deploy this dense platform for diverse workloads in space constrained environments and maintain it with ease by automating the most essential server lifecycle management tasks with HPE OneView and HPE iLO 5.
The HPE ProLiant DL360 Gen10 Server supports the Intel® Xeon® Scalable Processor Family with up to 28 cores, plus 2933 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB max. With the added performance that HPE Persistent Memory and 10 NVMe bring, the HPE ProLiant DL360 Gen10 means business. Deploy this dense platform for diverse workloads in space constrained environments and maintain it with ease by automating the most essential server lifecycle management tasks with HPE OneView and HPE iLO 5.
- Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks
- 800 W power supply unit (PSU) included
- RAID provides data reliability, fault tolerance and improves overall performance
- 32 GB powerful memory for any computational task
Technical Specifications
| Display & Graphics | |
| Graphics Memory Capacity | 16 MB |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C621 |
| Miscellaneous | |
| Security Features |
|
| Energy Star | Yes |
| Storage | |
| Optical Drive Type | No |
| Number of Hard Drives | No |
| Controllers | |
| Controller Type | 12Gb/s SAS |
| Serial ATA | |
| RAID Supported | Yes |
| Controller Model | MR416i-a/4GB with Smart Storage Battery |
| Power Description | |
| Plug/Connector Type | C13/C14 |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| Hot Swappable Power Supply | Yes |
| Maximum Power Supply Wattage | 800 W |
| Physical Characteristics | |
| Weight (Approximate) | 28.75 lb (13040 g) |
| Form Factor | Rack |
| Rack Height | 1U |
| Height | 1.69" (42.90 mm) |
| Width | 17.11" (434.60 mm) |
| Depth | 27.83" (707 mm) |
| General Information | |
| Product Type | Server |
| Manufacturer Part Number | P56955-B21 |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | ProLiant DL360 G10 Server |
| Product Line | ProLiant |
| Product Series | DL360 G10 |
| Brand Name | HPE |
| I/O Expansions | |
| "Number of Internal 2.5"" Bays" | 8 |
| Number of Total Expansion Bays | 8 |
| Total Number of Expansion Slots | 2 |
| Hot Swappable Bays | Yes |
| PCI Express x16 (Gen 3.x) Slots | 1 |
| PCI Express x8 (Gen 3.x) Slots | 1 |
| Number of SFF Bays | 8 |
| PCI Express Details | 2 PCIe: 1 x16 FH, 1 x8 LP |
| Interfaces/Ports | |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 4 |
| Network (RJ-45) | Yes |
| Remote Management | Yes |
| Total Number of USB Ports | 5 |
| Number of USB 3.0 Ports | 5 |
| Number of VGA Ports | 1 |
| Remote Management Controller | HPE iLO 5 |
| Processor | |
| Cache | 11 MB |
| Processor Speed | 2.10 GHz |
| Processor Type | Xeon Silver |
| Processor Model | 4208 |
| Processor Core | Octa-core (8 Core) |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 1 |
| Processor Generation | 2nd Gen |
| Memory | |
| Error Checking | ECC |
| Maximum Memory Supported | 1.54 TB |
| Signal Processing | Registered (Buffered) |
| Standard Memory | 32 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Occupied Memory Slots | 1 |
| Intel Optane Memory Ready | Yes |
| Memory Clock Speed | 2.93 GHz |
| Total Number of Memory Slots | 24 |
| Operating System | |
| Operating System | No |
| Operating System Supported | Windows Server 2016 Essential |
| Windows Server 2016 Standard | |
| Citrix XenServer | |
| ClearOS 7.6 | |
| Windows Server 2019 Datacenter | |
| Windows Server 2019 Essentials | |
| Windows Server 2019 Standard | |
| Windows Server 2022 Datacenter | |
| Windows Server 2022 Essentials | |
| Windows Server 2022 Standard | |
| Hyper-V | |
| Oracle Linux | |
| Red Hat Enterprise Linux 7.6 | |
| Red Hat Enterprise Linux 8 | |
| SUSE Linux Enterprise Server 12 SP3 | |
| SuSE Linux Enterprise Server 15 | |
| Ubuntu 18.04 LTS | |
| Windows Server 2012 R2 Datacenter | |
| Windows Server 2012 R2 Essentials | |
| Windows Server 2012 R2 Standard | |
| Windows Server 2016 Datacenter |
