About the product
Overview | HPE ProLiant DL20 Gen10 Plus server
The dense and compact HPE ProLiant DL20 Gen10 Plus server powered by Intel® Xeon® E and Pentium® Processors provides a unique blend of enterprise class capabilities & value. It offers outstanding configuration flexibility to cater to a wide variety of business requirements at an affordable price point. Deploy this dense platform for diverse workloads in space constrained environments and maintain it with ease by automating the most essential server lifecycle management tasks with HPE iLO 5.- Gigabit Ethernet port for ultra-fast network speeds
- 500 W power supply unit (PSU) included
- Experience high performance, built-in security and remote management capabilities with Intel Xeon 2.90 GHz processor
- RAID provides data reliability, fault tolerance and improves overall performance
- With 32 GB memory, improve system performance to execute complex applications
- 960 GB SSD is enough to store your essential documents and files, favorite songs, movies and pictures
Technical Specifications
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Warranty | |
| Additional Warranty Information | 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C256 |
| Display & Graphics | |
| Graphics Controller Model | G200 |
| Graphics Memory Capacity | 16 MB |
| Controllers | |
| Controller Type | Serial ATA |
| RAID Supported | Yes |
| Controller Model | Intel VROC |
| Miscellaneous | |
| Package Contents |
|
| Security Features |
|
| Environmentally Friendly | Yes |
| Energy Star | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 1U |
| Height | 1.70" (43.20 mm) |
| Width | 17.11" (434.60 mm) |
| Depth | 15.05" (382.20 mm) |
| Storage | |
| Optical Drive Type | No |
| Solid State Drive Interface | Serial ATA |
| Number of Hard Drives | No |
| Solid State Drive Configuration | 2 x 480GB |
| Total Solid State Drive Capacity | 960 GB |
| Number of Solid State Drives | 2 |
| I/O Expansions | |
| "Number of External 5.25"" Bays" | 1 |
| "Number of Internal 2.5"" Bays" | 4 |
| Number of Total Expansion Bays | 5 |
| Total Number of Expansion Slots | 2 |
| Hot Swappable Bays | Yes |
| Number of SFF Bays | 4 |
| PCI Express Details | 2 PCIe 4.0 slots |
| Memory | |
| Error Checking | ECC |
| Maximum Memory Supported | 128 GB |
| Signal Processing | Unregistered (Unbuffered) |
| Standard Memory | 32 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Occupied Memory Slots | 2 |
| Total Number of Memory Slots | 4 |
| Processor | |
| Cache | 12 MB |
| Processor Speed | 2.90 GHz |
| Processor Type | Xeon |
| Processor Model | E-2336 |
| Processor Core | Hexa-core (6 Core) |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| General Information | |
| Product Type | Server |
| Manufacturer Part Number | P63678-B21 |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | ProLiant DL20 G10 Plus Server |
| Product Line | ProLiant |
| Product Series | DL20 G10 Plus |
| Brand Name | HPE |
| Interfaces/Ports | |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Remote Management | Yes |
| Total Number of USB Ports | 5 |
| Number of USB 2.0 Ports | 1 |
| Number of VGA Ports | 2 |
| Remote Management Controller | iLO Management (standard), Intelligent Provisioning (standard), |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | Power Supply |
| Plug/Connector Type | C13/C14 |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Redundant Power Supply | Yes |
| Maximum Power Supply Wattage | 500 W |
| Operating System | |
| Operating System | No |
| Operating System Supported | Red Hat Enterprise Linux 8.4 |
| Red Hat Enterprise Linux 9.0 | |
| SuSE Linux Enterprise Server | |
| SUSE Linux Enterprise Server 12 SP5 | |
| SuSE Linux Enterprise Server 15 | |
| SUSE Linux Enterprise Server 15 SP3 | |
| Ubuntu 20.04 LTS | |
| Windows Server 2019 | |
| Windows Server 2019 Datacenter | |
| Windows Server 2019 Essentials | |
| Windows Server 2019 Standard | |
| Windows Server 2022 | |
| Windows Server 2022 Datacenter | |
| Windows Server 2022 Essentials | |
| Windows Server 2022 Standard | |
| Hyper-V | |
| Red Hat Enterprise Linux |
