About the product
Do you need to accelerate the performance of your read intensive applications?
HPE NVMe Mainstream Performance Read Intensive (RI) Enterprise and Datacenter Standard Form Factor (EDSFF) E3.S Solid State Drives (SSDs) are best suited for applications requiring a strong blend of high read IOPS, low latency and high endurance at a strong price point. NVMe SSDs communicate directly to applications via the PCIe bus to boost I/O bandwidth and reduce latency.
HPE NVMe Mainstream Performance EDSFF E3.S SSD replaces the traditional 2.5 inch small form factor SSD while supporting greater density of NVMe drives. It provides high-performance data transfers at rates faster than SAS or SATA SSDs. Designed to utilize the high bandwidth of PCIe Gen5 on servers with workloads high in reads such as read caching, web servers and boot/swap.
Features | High Performance, Exceptional Reliability, and Efficiency for Faster Business Results
HPE NVMe Mainstream Performance Read Intensive (RI) Enterprise and Datacenter Standard Form Factor (EDSFF) E3.S Solid State Drives (SSDs) are ideal for databases, cloud compute, containers, and hyperscale environments.
Achieve higher IOPS and lower latency to enhance the performance of your enterprise servers while maintaining data accuracy with full data-path error detection.
Improved thermals, power, and scalability provide better system efficiency for high I/O applications.
Faster PCIe Gen 5 technology only available with EDSFF E3.S SSDs
Improved Design and Efficiency for increased performance on Gen 11 Servers
Dramatically increase density with a 1U server that can fit 20 E3.S or 10 E3.S 2T drives, or a 2U server that can fit 36 E3.S or 18 E3.S 2T drives.
Improved power management and density while utilizing less power
- Store as many documents, pictures and videos as you need with 1.92 TB capacity
- With PCI Express NVMe 5.0 interface get superb reliability and high-speed data transfer
Technical Specifications
| Technical Information | |
| Storage Capacity | 1.92 TB |
| Interfaces/Ports | |
| Drive Interface | PCI Express NVMe |
| Drive Interface Standard | PCI Express NVMe 5.0 |
| Miscellaneous | |
| Device Supported | Data Center |
| Server | |
| Drive Performance | |
| Random 4KB Read | 1296099IOPS |
| Random 4KB Write | 160396IOPS |
| Endurance (DWPD) | 1 |
| Endurance Type | Read Intensive |
| General Information | |
| Product Type | Solid State Drive |
| Manufacturer Part Number | P69234-B21 |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | 1.92TB NVMe Gen5 Mainstream Performance Read Intensive E3S EC1 CD8P SSD |
| Brand Name | HPE |
| Physical Characteristics | |
| Weight (Approximate) | 1.19 lb (540 g) |
| Drive Type | Internal |
| Form Factor | E3.S |
| Height | 4.57" (116 mm) |
| Width | 7.87" (200 mm) |
| Depth | 10" (254 mm) |
| Hot Pluggable | Yes |
