About the product
HPE ProLiant DL20 Gen11
The dense and compact HPE ProLiant DL20 Gen11 server powered by Intel® Xeon® E and Pentium® Processors provides a unique blend of enterprise class capabilities & value. It offers mobility, easy deployment and outstanding configuration flexibility to cater to a wide variety of business requirements at an affordable price point. Deploy this dense platform for diverse workloads in space constrained environments and maintain it with ease by automating the most essential server lifecycle management tasks with HPE iLO 6.
- Gigabit Ethernet enables higher aggregate data transfer capacity resulting in better overall performance
- 2 x 500 W power supply unit (PSU) for your system's power requirements
- Experience high performance, built-in security and remote management capabilities with Intel Xeon 2.90 GHz processor
- 32 GB powerful memory for any computational task
- 1.92 TB SSD provides performance and superior data storage for storing a variety of files including media, documents and more
Technical Specifications
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Warranty | |
| Additional Warranty Information | Server warranty includes 3-year parts, 3-year labor, 3-year onsite support with next business day response. |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C262 |
| Display & Graphics | |
| Graphics Controller Model | G200 |
| Graphics Memory Capacity | 16 MB |
| Controllers | |
| Controller Type | 12Gb/s SAS |
| Serial ATA | |
| RAID Supported | Yes |
| Controller Model | MR408i-o Gen11 |
| Operating System | |
| Operating System Supported | Windows Server |
| Ubuntu | |
| SuSE Linux Enterprise Server | |
| Red Hat Enterprise Linux | |
| Storage | |
| Solid State Drive Interface | Serial ATA |
| Solid State Drive Configuration | 2 x 960GB |
| Total Solid State Drive Capacity | 1.92 TB |
| Number of Solid State Drives | 2 |
| Memory | |
| Error Checking | ECC |
| Maximum Memory Supported | 128 GB |
| Signal Processing | Unregistered (Unbuffered) |
| Standard Memory | 32 GB |
| Memory Technology | DDR5 SDRAM |
| Number of Occupied Memory Slots | 1 |
| Miscellaneous | |
| Package Contents |
|
| Security Features |
|
| Environmentally Friendly | Yes |
| Energy Star | Yes |
| Energy Efficiency Certification | ENERGY STAR 4.0 |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Physical Characteristics | |
| Weight (Approximate) | 26.46 lb (12000 g) |
| Form Factor | Rack |
| Rack Height | 1U |
| Height | 1.70" (43.20 mm) |
| Width | 17.11" (434.60 mm) |
| Depth | 14.90" (378.40 mm) |
| I/O Expansions | |
| "Number of External 5.25"" Bays" | 1 |
| "Number of Internal 2.5"" Bays" | 4 |
| Number of Total Expansion Bays | 5 |
| Total Number of Expansion Slots | 3 |
| Hot Swappable Bays | Yes |
| Number of SFF Bays | 4 |
| PCI Express Details | 1x PCIe 5.0 CEM slot, 1 Internal OCP Storage Controller slot, 1 External OCP 3.0 Network Controller slot |
| Processor | |
| Cache | 18 MB |
| Processor Speed | 2.90 GHz |
| Processor Type | Xeon |
| Processor Model | E-2436 |
| Processor Core | Hexa-core (6 Core) |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| General Information | |
| Product Type | Server |
| Manufacturer Part Number | P71682-005 |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | ProLiant DL20 Gen11 Server |
| Product Line | ProLiant |
| Product Series | DL20 G11 |
| Brand Name | HPE |
| Power Description | |
| Input Voltage | 130 V AC |
| 120 V AC | |
| Power Source | Power Supply |
| Plug/Connector Type | C13/C14 |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Redundant Power Supply | Yes |
| Hot Swappable Power Supply | Yes |
| Maximum Power Supply Wattage | 500 W |
| Interfaces/Ports | |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 4 |
| Network (RJ-45) | Yes |
| DisplayPort | Yes |
| Remote Management | Yes |
| Total Number of USB Ports | 10 |
| Number of USB 2.0 Ports | 1 |
| Number of VGA Ports | 1 |
| Number of DisplayPorts | 1 |
| Remote Management Controller | iLO Management |
