About the product
For installation flexibility, Vertiv Liebert GXT4 5-6kVA UPS models allow you to choose from several different input/output power wiring configurations made possible by the use of removable power output distribution boxes (PODs) that simply plug into the rear of the UPS. When the ease of plug-and-play power connections is desired, optional versions of the power distribution box convert Vertiv Liebert GXT4 5-6kVA UPS units to a cord-type input with receptacles for output distribution, and also offers maintenance bypass capability that allows hot-swapping of the entire UPS without interruption of power to the connected load.
- Input power connector: L14-30, output receptacles: four 5-20R, two L6-30R
- Designed for Vertiv Liebert GXT4 5-6kVA RT208 UPS
- 10.5 ft. power cable
- Circuit breaker
- Built-in maintenance bypass
Technical Specifications
| Miscellaneous | |
| Additional Information | Maintenancy bypass |
| Compatibility | Liebert UPS Systems:
|
| Country of Origin | China |
| Physical Characteristics | |
| Weight (Approximate) | 8.60 lb (3900.89 g) |
| Height | 3.46" (88 mm) |
| Width | 5.20" (132 mm) |
| Depth | 15.47" (393 mm) |
| Technical Information | |
| Receptacle Type | NEMA 5-20R |
| NEMA L6-30R | |
| Receptacle Detail | 2 x NEMA L6-30R |
| 4 x NEMA 5-20R | |
| General Information | |
| Product Type | PDU |
| Manufacturer Part Number | PD2-003 |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Manufacturer | Vertiv |
| Product Model | PD2-003 |
| Product Name | PD2-003 6-Outlets PDU |
| Brand Name | Vertiv Liebert |
