StarTech.com 1 Port Low Profile PCI Express Serial Card - 16550 - Add a RS

Name: StarTech.com 1 Port Low Profile PCI Express Serial Card - 16550 - Add a RS
Brand: Startech
SKU: 230844DIS
Price: 76.99 CAD
Availability: InStock

$76.99 CAD

~~$86.99 CAD~~ $76.99 CAD

-11% OFF Ask for quote

Shipping calculated at checkout.

StarTech.com 1 Port Low Profile PCI Express Serial Card - 16550 - Add a RS-232 serial port to your standard or small form factor computer through a PCI Express expansion slot - pci express serial card - pci-e serial card - pci express RS232 - rs232 card - pci serial adapter

VPNPEX1S553LP SKU:230844DIS UPC:65030841733

One high speed RS232 serial port with data transfer rate up to 460.8 Kbps
Ships with half-height/low profile mounting bracket, includes standard bracket
Selectable power output on pin 9 for the serial port

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

About the product

One high speed RS232 serial port with data transfer rate up to 460.8 Kbps

Ships with half-height/low profile mounting bracket, includes standard bracket

Selectable power output on pin 9 for the serial port

Native single-chip, single lane PCI Express

Single chip design optimizes speed and reliability

Compliant with PCI Express base specifications revision 1.1a

Automated out-of-band flow control using CTS/RTS and DSR/DTR

Automated in-band software flow control using programmable Xon/Xoff in both directions

256 Byte FIFO

Technical Specifications

Interfaces/Ports
Number of Serial Ports (External)	1
Miscellaneous
Additional Information	Native single-Chip, single lane PCI Express; 48% less cpu load, and increased performance. Pre-configured for low profile/half-height systems but includes a full profile bracket for versatility. Easy to install and use with full step-by-step instructions saving time and hassle. Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64), XP Embedded, POS Ready 2009, Embedded System 2009, CE 5.0/6.0, 2000, 98SE, 95, DOS Windows Server® 2012, 2008 R2, 2003 Mac OS® 10.4 and later (tested up to 10.10) Linux kernel 2.6.x
Package Contents	1 Port Low Profile Native RS232 PCI Express Serial Card with 16550 UART Full Profile Bracket Driver CD Instruction Manual
Country of Origin	Taiwan
Environmentally Friendly	Yes
TAA Compliant	Yes
Physical Characteristics
Weight (Approximate)	1.60 oz (45.36 g)
Form Factor	Plug-in Card
Length	4.10" (104.14 mm)
Height	0.80" (20.32 mm)
Width	3.10" (78.74 mm)
Card Height	Low-profile
Technical Information
Host Interface	PCI Express x1
Data Transfer Rate	460kB/s
Platform Supported	Linux
	PC
	Mac
UART Type	16550
General Information
Product Type	Serial Adapter
Manufacturer Part Number	PEX1S553LP
Manufacturer Website Address	http://www.startech.com
Packaged Quantity	1
Manufacturer	StarTech.com
Product Model	PEX1S553LP
Product Name	1 Port Low Profile Native RS232 PCI Express Serial Card with 16550 UART
Brand Name	StarTech.com
