About the product
This PCI Express IDE Controller Adapter Card provides a cost-effective way to use legacy drives with modern computers, by converting a PCI Express port into an IDE port.
Providing data burst transfer rates of up to 133MBps and support for PIO 0/1/2/3/4 and UDMA 33/66/100/133 operating modes, the IDE controller card offers an efficient way to add an IDE channel with support for two IDE drives on the same channel.
A complete dual profile solution, the PCI Express IDE controller card provides both standard and low profile brackets for adapting to slimline or small form factor system applications.
More from the Manufacturer
- 2-channel IDE port supports two drives
- 48-bit LBA support
- Supports ATA/ATAPI commands
- Supports UDMA 6 mode which supports transfer rates up to 133 MBps
- Includes a low profile installation bracket
Technical Specifications
| Interfaces/Ports | |
| Total Number of IDE Ports | 1 |
| Physical Characteristics | |
| Weight (Approximate) | 4.20 oz (119.07 g) |
| Form Factor | Plug-in Card |
| Technical Information | |
| Host Interface | PCI Express x1 |
| Controller Type | Ultra ATA/133 (ATA-7) |
| Number of Physical Drive Supported | 2 |
| Miscellaneous | |
| Package Contents |
|
| Platform Supported | PC |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| General Information | |
| Product Type | Ultra ATA Controller |
| Manufacturer Part Number | PEX2IDE |
| Manufacturer Website Address | http://www.startech.com |
| Packaged Quantity | 1 Each |
| Manufacturer | StarTech.com |
| Product Name | 1-Port PCI Express IDE Controller Adapter Card |
| Brand Name | StarTech.com |
