Axis Communications
AXIS M3086-V 4 Megapixel Indoor Network Camera - Color - Mini Dome - White - H.
AXIS M3086-V 4 Megapixel Indoor Network Camera - Color - Mini Dome - White - H.
VPN:02374-001 SKU:PHS276889 UPC:
- Features RGB CMOS sensor
- Up to 2688 x 1512 resolution for surveillance in real-time
- For remote surveillance needs, this network camera is best suited
Couldn't load pickup availability
Volume discount available - Ask for quote..
View full details



Recently Viewed
AXIS M3086-V 4 Megapixel Indoor Network Camera - Color - Mini Dome - White - H.
Product information summary

About the product
Fixed 4 MP mini dome with deep learning
- Great image quality in 4 MP
- Compact, discreet design
- WDR and Lightfinder
- Support for analytics with deep learning
- Built-in cybersecurity features
This cost-efficient, compact mini dome delivers great image quality in challenging light conditions. And, with a deep learning processing unit, you can benefit from advanced analytics based on deep learning on the edge.
Great image quality
AXIS M3086-V offers great 4 MP image quality even in challenging light conditions. Thanks to Wide Dynamic Range (WDR), it ensures clarity even when there's both dark and light areas in the scene. And, with Lightfinder, you get sharp, color images even in low light. Furthermore, it offers a wide-angle view of 130° and comes factory-focused so there's no manual focusing required.
Extended possibilities
AXIS M3086-V offers support for intelligent analytics based on deep learning on the edge. This means it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video. AXIS Object Analytics comes preinstalled and knows what to detect so you can focus on objects of interest - all tailored to your specific needs. Additionally, with support for ACAP, you can add value to your system with tailor-made applications. Furthermore, this compact dome offers the flexibility to add audio or I/O connectivity using accessories.
Compact and cost-efficient
This cost-efficient mini dome offers a wide range of mounting accessories for flexible and discreet installation. With bayonet-fitted casing, it simply twists on and off for fast, convenient installation. Compact in design, this easy-to-install, vandal-resistant camera is protected against redirection and defocusing as well as dust and dripping water. It offers Axis Zipstream with H.264/H.265 for reduced bandwidth and storage requirements. And thanks to edge storage you can record directly to an onboard memory card. Furthermore, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network.
- Features RGB CMOS sensor
- Up to 2688 x 1512 resolution for surveillance in real-time
- For remote surveillance needs, this network camera is best suited
Technical Specifications
Power Description | |
Power Source Type | PoE |
Storage | |
Storage Type | Memory Card |
Technical Information | |
HD Recording | Yes |
Exposure | |
Longest Shutter Speed | 1/5 Second |
Shortest Shutter Speed | 1/38500 Second |
Interfaces/Ports | |
HDMI | Yes |
Network (RJ-45) | Yes |
Network & Communication | |
Connectivity Technology | Wired |
Remote Management | Yes |
Environmental Conditions | |
Minimum Operating Temperature | 32°F (0°C) |
Maximum Operating Temperature | 113°F (45°C) |
Maximum Operating Humidity | 85% |
Display & Graphics | |
Color Supported | Color |
Image Sensor Type | RGB CMOS |
Effective Camera Resolution | 4 Megapixel |
Field of View | Horizontal field of view: 130° Vertical field of view: 93° |
Lens | |
Lens Type | Fixed |
Maximum Aperture | f/2.1 |
Maximum Focal Length | 2.4 mm (0.09") |
Lens Included | Yes |
General Information | |
Product Type | Network Camera |
Manufacturer Part Number | 02374001 |
Manufacturer Website Address | http://www.axis.com |
Manufacturer | Axis Communications |
Product Model | M3086-V |
Product Name | M3086-V Dome Camera |
Product Series | M30 |
Brand Name | AXIS |
Video | |
Video Formats | H.264 |
H.264 (MPEG-4 Part 10/AVC) | |
H.264H | |
H.264M | |
H.265 | |
Zipstream | |
H.265 (MPEG-H Part 2/HEVC) | |
Maximum Video Resolution | 2688 x 1512 |
Maximum Frame Rate | 30 fps |
Physical Characteristics | |
Weight (Approximate) | 5.29 oz (150 g) |
Durability | Water Resistant |
Vandal Resistant | |
Impact Resistant | |
Dust Resistant | |
Form Factor | Mini Dome |
Mount Type | Ceiling Mount |
Wall Mount | |
Diameter | 3.98" (101 mm) |
Height | 2.20" (56 mm) |
Product Color | White |
Color Family | White |
Miscellaneous | |
Features | Day/Night |
Vehicle Detection | |
Removable IR Cut-off Filter | |
Password Protection | |
Built-in Microphone | |
Cross Line Detection | |
Wide Dynamic Range | |
HTTPS Encryption | |
Human Detection | |
Multi-view Stream | |
TAA Compliant | Yes |
Indoor/Outdoor | Indoor |
Impact Protection Rating | IK08 |
Ingress Protection Rating | IP42 |
