2N IP Force Video Door Phone Sub Station - CMOS - 135° Horizontal - 109° Vertica

Name: 2N IP Force Video Door Phone Sub Station - CMOS - 135° Horizontal - 109° Vertica
Brand: Axis Communications
SKU: PHS299682
Availability: OutOfStock

$0.00 CAD

~~$0.00 CAD~~ $0.00 CAD

-Liquid error (snippets/price line 128): divided by 0% OFF Ask for quote

Shipping calculated at checkout.

2N IP Force Video Door Phone Sub Station - CMOS - 135° Horizontal - 109° VerticalFull-duplexAluminum - CCTV Camera, Video Management System (VMS)

VPN:01334-001 SKU:PHS299682 UPC:

Built for extreme conditions
Professional night vision
Clear sound in noisy environments

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

2N IP Force Video Door Phone Sub Station - CMOS - 135° Horizontal - 109° Vertica

About the product

TOUGHEST IP INTERCOM IN THE WORLD

2N® IP Force is an extremely durable IP intercom that can withstand even the most demanding conditions. It provides for visitor communication monitoring and access control. Take advantage of its superior features for maximum site security.

Built for extreme conditions
Professional night vision
Clear sound in noisy environments
Durable access control solution
Wide-angle HD camera
Easy integration into CCTV and VMS

Technical Specifications

Power Description
Input Voltage	12 V DC
Technical Information
Communication Mode	Full-duplex
Camera
Horizontal Viewing Angle	135°
Vertical Viewing Angle	109°
Image Sensor Type	CMOS
Miscellaneous
Additional Information	Signalling Protocol: SIP (UDP, TCP, TLS) Button: Button design: Transparent, white backlit buttons with easily replaceable label Count of buttons: 1 Numerical keypad: Optional Audio: Microphone: 2 integrated microphones Amplifier: 10 W (class D) Speaker: 10 W Volume control: Adjustable with automatic adaptive mode Audio Stream: Protocols RTP/RTSP Codecs G.711, G.722, G.729, L 16/16kHz Camera HD: JPEG resolution 1280 (H) x 960 (V) Video resolution 640 (H) × 480 (V) Frame rate Up to 30 snapshots/s Sensor sensitivity: 5.6 V/lux-sec (550 nm) / 1.9 V/lux-sec (550 nm) Infrared light: Yes Video stream: Protocols: RTP/RTSP/HTTP Codecs: H.263, H.263+, H.264, MPEG-4, M-JPEG IP camera function: Yes, ONVIF v2.4 profile S compatible Interface: PoE: PoE 802.3af (Class 0 - 12,95 W) LAN: 10/100BASE-TX with Auto-MDIX, RJ-45 Recommended cabling: Cat-5e or higher Passive switch: NO/NC contacts, max. 30 V/1A AC/DC Active switch output: 9 up to 13 V DC depending on power supply, max. 700 mA Mechanical Properties: Operating temperature -40°F to 131 °F Storage temperature -40 °F to 158 °F humidity: 10 % - 95 % (non-condensing) Covering level IP69K and IK10 RFID Card Reader: Supported frequencies: 125kHz and 13.56MHz 125 kHz: EM4100, EM4102, HID Proximity 13.56 MHz: ISO14443A, ISO14443B, ISO15693, NFC support reads UID (CSN) reads PACs ID (iCLASS SIO-enabled cards) - only secured cards
Application/Usage	Video Management System (VMS)
	CCTV Camera
Country of Origin	Czech Republic
General Information
Product Type	Video Door Phone Sub Station
Manufacturer Part Number	01334-001
Manufacturer Website Address	http://www.axis.com
Manufacturer	Axis Communications
Product Name	IP Force Video Door Phone Sub Station
Product Line	IP Force
Brand Name	2N
Physical Characteristics
Weight (Approximate)	4.41 lb (1999.89 g)
Durability	Water Resistant
Height	8.54" (216.99 mm)
Width	4.29" (108.99 mm)
Depth	3.27" (83.01 mm)
Product Color	Black
Product Material	Aluminum
