About the product
6 MP outdoor-ready with 360° panoramic view and audio capture:
With its 6 MP sensor, AXIS M3077-PLVE offers excellent image quality and a complete 180° or 360° overview, indoors or out, around the clock. It features two built-in microphones allowing for audio surveillance and detection. This compact mini dome offers dewarped views such as panorama, quad, corner, and corridor views directly from the camera. It includes Axis Lightfinder and Axis Forensic WDR for true colors and great details in challenging light or near darkness. And, Axis OptimizedIR for surveillance in pitch darkness.
- Features RGB CMOS sensor
- Up to 2560 x 1920 resolution for surveillance in real-time
- Up to 2560 x 1920 video resolution
- Provides night vision of objects at a distance of up to 65.62 ft (20 m)
Technical Specifications
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Power Source Type | PoE |
| Storage | |
| Storage Type | Memory Card |
| Exposure | |
| Longest Shutter Speed | 1 Second |
| Shortest Shutter Speed | 1/16000 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Environmental Conditions | |
| Minimum Operating Temperature | -40°F (-40°C) |
| Maximum Operating Temperature | 122°F (50°C) |
| Maximum Operating Humidity | 100% |
| Display & Graphics | |
| Color Supported | Color |
| Image Sensor Type | RGB CMOS |
| Effective Camera Resolution | 6 Megapixel |
| Field of View | Horizontal field of view: 183° Vertical field of view: 183° |
| Lens | |
| Lens Type | Fixed |
| Maximum Aperture | f/2 |
| Maximum Focal Length | 1.6 mm (0.06") |
| Lens Included | Yes |
| Technical Information | |
| Night Vision | Yes |
| HD Recording | Yes |
| Night Vision Distance | 65.62 ft (20 m) |
| Night Vision Type | Infrared |
| Video | |
| Video Formats | H.265 |
| H.265 (MPEG-H Part 2/HEVC) | |
| MJPEG | |
| H.264 (MPEG-4 Part 10/AVC) | |
| H.264 | |
| Maximum Video Resolution | 2560 x 1920 |
| Maximum Frame Rate | 60 fps |
| General Information | |
| Product Type | Network Camera |
| Manufacturer Part Number | 02018001 |
| Manufacturer Website Address | http://www.axis.com |
| Manufacturer | Axis Communications |
| Product Model | M3077 |
| Product Name | M3077-PLVE Network Camera |
| Product Series | M30 |
| Brand Name | AXIS |
| Physical Characteristics | |
| Weight (Approximate) | 1.54 lb (700 g) |
| Form Factor | Dome |
| Mount Type | Wall Mount |
| Pole Mount | |
| Pendant Mount | |
| Lighting Track Mount | |
| Ceiling Mount | |
| Conduit Mount | |
| Corner Mount | |
| Parapet Mount | |
| Diameter | 5.87" (149 mm) |
| Height | 2.60" (66 mm) |
| Product Color | White |
| Color Family | White |
| Miscellaneous | |
| Package Contents |
|
| Features | Wide Dynamic Range |
| Video Management System | |
| Tampering Alarm | |
| Noise Reduction | |
| Privacy Masking | |
| Multi-view Stream | |
| Motion Detection | |
| Day/Night | |
| Built-in Microphone | |
| Built-in IR LED | |
| Automatic White Balance | |
| Auto Gain Control | |
| Audio Detection | |
| PTZ | |
| Removable IR Cut-off Filter | |
| SD Card Local Storage | |
| Country of Origin | Thailand |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP66 |
| NDAA Compliant | Yes |
