AXIS I8016-LVE Network Video Intercom - 5 Megapixel - CMOS - 140° Horizontal - 1

Name: AXIS I8016-LVE Network Video Intercom - 5 Megapixel - CMOS - 140° Horizontal - 1
Brand: Axis Communications
SKU: PHS652409
Availability: OutOfStock

$0.00 CAD

~~$0.00 CAD~~ $0.00 CAD

-Liquid error (snippets/price line 128): divided by 0% OFF Ask for quote

Shipping calculated at checkout.

AXIS I8016-LVE Network Video Intercom - 5 Megapixel - CMOS - 140° Horizontal - 114° VerticalFull-duplexStainless Steel, Plastic, Zinc - Surveillance System, Access Control - TAA Compliant

VPN:01995-001 SKU:PHS652409 UPC:

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

AXIS I8016-LVE Network Video Intercom - 5 Megapixel - CMOS - 140° Horizontal - 1

About the product

AXIS I8016-LVE Network Video Intercom is a compact and highly robust network intercom designed for two-way communication, video identification, and remote entry control. It offers 5 MP resolution with invisible IR night vision, and exceptional audio volume with echo and noise cancellation to ensure reliable 24/7 identification even in the most demanding situations. Based on open IP standards and interfaces, this network intercom offers great integration possibilities and is a perfect complement to any video surveillance system. Furthermore, it features multiple inputs and outputs for remote control of door locks and other equipment.

High-quality audio and video
Easy installation with PoE
Open interface with IP phone integration, SIP support
Anti-ligature, vandal-resistant IK10-rated
IP66/IP69-rated with wall-mount

Technical Specifications

Technical Information
Communication Mode	Full-duplex
Camera
Camera Resolution	5 Megapixel
Horizontal Viewing Angle	140°
Vertical Viewing Angle	114°
Image Sensor Type	CMOS
General Information
Product Type	Video Door Phone Sub Station
Manufacturer Part Number	01995-001
Manufacturer Website Address	http://www.axis.com
Manufacturer	Axis Communications
Product Model	I8016-LVE
Product Name	I8016-LVE Network Video Intercom
Brand Name	AXIS
Miscellaneous
Additional Information	Minimum illumination: Color: 0.16 lux at 50 IRE, F2.2 B/W: 0.00 lux at 50 IRE, F2.2, with IR illumination on System on chip (SoC): Model: ARTPEC-7 Memory: 2048 MB RAM, 512 MB Flash Video: Video compression: H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles H.265 (MPEG-H Part 2/HEVC) Main Profile Motion JPEG Resolution: 2592x1944 240x160 Frame rate: Up to:30/25 fps (60/50 Hz) in all resolutions Video streaming: Multiple, individually configurable streams in H.264, H.265 and Motion JPEG Axis Zipstream technology in H.264 and H.265 Controllable frame rate and bandwidth VBR/ABR/MBR H.264/H.265 Video streaming indicator Image settings: Saturation, contrast, brightness, sharpness, forensic WDR: up to 120 dB depending on scene, white balance, day/night threshold, tone mapping, exposure mode, exposure zones, defogging, compression, text and image overlay, polygon privacy mask Audio: Audio encoding: 24bit LPCM, AAC-LC 8/16 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16 kHz Configurable bit rate Audio input/output: Line input, line output, built-in microphone (can be disabled), built-in speaker, automatic gain control Built-in speaker 78 dB sound pressure at 1 kHz at 1 m distance (84 dB at 0.5 m / 20 in) Network: Security: Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1x (EAP-TLS) a network access control, digest authentication, user access log, centralized certificate management, brute force delay protection, signed firmware, secure boot, protection of cryptographic keys with FIPS 140-2 certified TPM 2.0 module, Axis Edge Vault with Axis device ID Supported protocols: IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, NTCIP, SIP, LLDP, Syslog, Link-Local address (ZeroConf) Storage: Support for microSD/microSDHC/microSDXC card and encryption Recording to network-attached storage (NAS) Mounting: Recessed mounting using US 2-Gang-, 4 inch square installation boxes or AXIS TA8201 Recessed Mount Wall Mounting using TI8202 Wall Mount Back Box Wall Mounting with conduit pipe using TI8202 Wall Mount Back Box and TI8603 Conduit Adapter Operating conditions: -40 °C to 60 °C (-40 °F to 140 °F) Start-up temperature: -40 °C (-40 °F ) Humidity 10-100% RH (condensing)
Application/Usage	Surveillance System
	Access Control
Package Contents	I8016-LVE Network Video Intercom Installation Guide Windows Decoder 1-user License Terminal Block Connector Allen Key (Resitorx 10)
Country of Origin	Poland
TAA Compliant	Yes
NDAA Compliant	Yes
Physical Characteristics
Weight (Approximate)	900 g
Durability	Vandal Resistant
Height	4.88" (124 mm)
Width	4.88" (124 mm)
Product Color	Black
Product Material	Plastic
	Zinc
	Stainless Steel
