About the product
Offering 180°/360° coverage and no blind spots, this fisheye camera supports advanced analytics based on deep learning on the edge. Its ultra-compact size makes it ideal for wherever you need high-quality indoor surveillance.
Great video performance
AXIS M4328-P offers a complete overview with outstanding sharpness, great detail, and no blind spots. This 12 MP camera delivers 360° or 180° panoramic overviews. It includesAxis Lightfinder and Axis Forensic WDR for true colors and great details in challenging light or near darkness. With its stereoscopic lens and digital PTZ, you can choose what to see in the view areas and at what zoom level in up to four areas simultaneously. Furthermore, built on ARTPEC-8, the latest Axis system-on-chip (SoC), this panoramic camera enables improved image processing and great image quality.
Deep learning on the edge
This indoor fisheye camera includes adeep learning processing unit (DLPU)enabling improved processing and storage capabilities. Plus, you can collect and analyze even more data than before - on the edge. Additionally, it delivers valuablemetadata, facilitating fast, easy, and efficient forensic search capabilities in live or recorded video. Thanks to AXIS Object Analytics, it's possible to detect and classify moving objects in a scene - all tailored to specific needs. Furthermore, with support for ACAP version 4, you can add value to your system with tailor-made applications based on deep learning on the edge.
Great look and ease of installation
This discreet, ultra-compact, affordable camera is quick and easy to install. With accessory casings available, it can also be repainted to blend in with any surroundings. It's delivered factory-focused. And, thanks to digital roll functionality, you can remotely adjust the rotation of the camera overview - no need to do it manually on the camera. Furthermore, AxisZipstream, with support for H.264 and H.265, significantly reduces bandwidth and storage requirements without compromising image quality.
- Features RGB CMOS sensor
- Up to 3840 x 2160 video resolution
Technical Specifications
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Power Source Type | PoE |
| Storage | |
| Storage Type | Memory Card |
| Exposure | |
| Longest Shutter Speed | 1/2 Second |
| Shortest Shutter Speed | 1/8100 Second |
| Technical Information | |
| Recording Formats | 4K |
| HD Recording | Yes |
| Lens | |
| Lens Type | Fixed |
| Maximum Aperture | f/2.2 |
| Maximum Focal Length | 1.2 mm (0.05") |
| Lens Included | Yes |
| Display & Graphics | |
| Color Supported | Color |
| Image Sensor Size | 1/2.3" |
| Image Sensor Type | RGB CMOS |
| Effective Camera Resolution | 12 Megapixel |
| Field of View | Horizontal field of view: 182° Vertical field of view: 182° |
| General Information | |
| Product Type | Network Camera |
| Manufacturer Part Number | 02637004 |
| Manufacturer Website Address | http://www.axis.com |
| Manufacturer | Axis Communications |
| Product Model | M4328-P |
| Product Name | M4328-P Panoramic Camera |
| Product Series | M43 |
| Brand Name | AXIS |
| Physical Characteristics | |
| Weight (Approximate) | 10.58 oz (300 g) |
| Form Factor | Fisheye |
| Mount Type | Gang Box Mount |
| Junction Box Mount | |
| Tripod Mount | |
| Bracket Mount | |
| Diameter | 3.98" (101 mm) |
| Height | 2.01" (51 mm) |
| Product Color | White |
| Video | |
| Video Formats | H.264 |
| H.264B | |
| H.264B (MPEG-4 Part 10/AVC) | |
| H.264H | |
| H.264H (MPEG-4 Part 10/AVC) | |
| H.264M | |
| H.264M (MPEG-4 Part 10/AVC) | |
| Zipstream | |
| H.265 | |
| H.265 (MPEG-H Part 2/HEVC) | |
| Motion JPEG | |
| Maximum Video Resolution | 3840 x 2160 |
| Maximum Frame Rate | 30 fps |
| Miscellaneous | |
| Package Contents |
|
| Features | Day/Night |
| Human Detection | |
| Mirror | |
| Noise Reduction | |
| Privacy Masking | |
| Vehicle Detection | |
| Video Management System | |
| White Balance | |
| Wide Dynamic Range | |
| 2D Noise Reduction | |
| 3D Digital Noise Reduction | |
| Country of Origin | Cambodia |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Indoor/Outdoor | Indoor |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| Network & Communication | |
| Protocols | SFTP |
| RTSP | |
| SMTP | |
| SNMP | |
| SNMPv1/v2c/v3 (MIB2) | |
| SRTP | |
| SSH | |
| Syslog | |
| TCP | |
| TLS | |
| UDP | |
| UPnP | |
| VoIP | |
| ZeroConf | |
| SIP | |
| RTP | |
| RTCP | |
| 802.1X | |
| CDP | |
| CIFS/SMB | |
| DDNS | |
| DHCPv4/v6 | |
| DiffServ (QoS) | |
| DNS/DNSv6 | |
| FTP | |
| HTTP | |
| HTTPS | |
| ICMPv4/ICMPv6 | |
| IGMPv1/v2/v3 | |
| IPv4 | |
| IPv6 USGv6 | |
| LLDP | |
| mDNS (Bonjour) | |
| MQTT v3.1.1 | |
| NTP | |
| NTS | |
| ONVIF | |
| Connectivity Technology | Wired |
| Ethernet Technology | Fast Ethernet |
| Remote Management | Yes |
