Uniview POE Injector, 50V (60W) Overview
PWR-DC5712-P is a long-distance dual port network power supply device, the max distance transmission is 100 meters and the max power is 60W. The device can simultaneously supply power to two standard PD devices (such as video phones, PTZ cameras, smart lights, and wireless CPE, AP, etc.).1000Mbps transmission rate enables PD equipment to obtain stable long-distance power supply while ensuring a smooth operation of highspeed network equipment.
Uniview POE Injector Features
- PoE++ power supply standard; Output power consumption up to 60W
- Double PoE Input/Output, Support IEEE 802.3af/at/bt
- Higher conversion efficiency (90%); Lower heat radiation;
- Working Temperature: -30??55?;
- 6KV lightning protection; 8KV ESD;
- No fan, no noise, dustproof;
- LEDs indicate operation status.
Uniview POE Injector Specifications
Interface
- Input Voltage: 100-240V AC @50/60Hz
- Data Input/ PoE output: 2×RJ45
PoE
- PoE Power Supply Type: End-span/Mid-span
- PoE Power Output: DC 52V/60 watts max
- Power Pin Assignment:
- Pair1:1/2?+??3/6 ( - )
- Pair2:4/5?+??7/8 ( - )
Ethernet Port
- Transmission Rate: 10/100M /1000Mbps
- Distance: 100m?Max.?
Status
- Power LED: 1 (Red)
- PoE LED: 1 (Orange)
Protection
- Surge Protection:
- P Power: 1KV(Differential Mode),2KV(Common Mode)1.2/50us?8/20us
- Ethernet: 2KV(Differential Mode),6KV(Common Mode)10/7000us
- ESD:
- 1a Contact Discharge Level 3
- 1b Air Discharge Level 3
- Per: IEC61000-4-2
- Surge Protection:
Environment
- Working Temperature: -30??55?
- Storage Temperature: -10??85?
- Humidity (Non-condensing): 0?95%
Mechanics
- Dimension (LxWxH): 112mm×45mm×32mm
- Material: ABS Plastics
- Color: Black
