Qnap

Qnap Qgd-1602P-C3758: 8 2.5Gbe Poe Ports(4 Port Ieee 803.3Bt Poe +

Qnap Qgd-1602P-C3758: 8 2.5Gbe Poe Ports(4 Port Ieee 803.3Bt Poe +

Regular price $2,718.56 CAD
Regular price $2,990.42 CAD Sale price $2,718.56 CAD
-9% OFF Ask for quote
Shipping calculated at checkout.
Qnap Qgd-1602P-C3758: 8 2.5Gbe Poe Ports(4 Port Ieee 803.3Bt Poe ++ Supply 90W, 4 Port 803.3At Poe ++ Supply 30W), 8 1Gbe Poe Ports( 8 Port 803.3At

VPN:QGD-1602P-C3758-16G-US SKU:T993922 UPC:885022019885

Volume discount available - Ask for quote..

View full details

Recently Viewed

Qnap Qgd-1602P-C3758: 8 2.5Gbe Poe Ports(4 Port Ieee 803.3Bt Poe +

Product information summary

Qnap Qgd-1602P-C3758: 8 2.5Gbe Poe Ports(4 Port Ieee 803.3Bt Poe +

About the product

The QNAP QGD-1602P is the worlds first PoE managed switch series that supports Virtual Machines (VMs). Featuring 2.5GbE and 10GbE SFP+ ports and up to 90-watt PoE output, the QGD-1602P allows you to build a high-speed and high-power PoE network infrastructure for Wi-Fi 6 Access Points and Routers. With a dual-CPU design, the QGD-1602P uses Intel Atom multi-core 2.2GHz processors with two SATA drive bays to support VM and QTS applications. The QGD-1602P not only fulfills IP surveillance, network security, wireless AP management, and storage expansion applications, but also integrates QuWAN to form a SD-WAN architecture with other QNAP devices across multiple sites, helping to build a resilient and secure IT infrastructure. With 20GbE internal bandwidth capacity and Intel QuickAssist Technology (Intel QAT), the QGD-1602P achieves the high-performance transmission required for edge computing virtualization and IPsec VPN, and offers SMBs a cost-optimized and centrally managed LAN deployment solution.

Technical Specifications

Primary Information
Storage Device Type: Network Storage Server
Cabinet Form Factor: Rack-Mountable
Processor / Manufacturer: Intel
Processor / Type: Atom
Processor / Clock Speed: 2.2 GHz
Processor / Number: C3758
Multi-Core Technology: Quad-Core
RAM / Technology: DDR4
RAM / Total Installed Size: 16 GB
RAM / Max Supported Size: 64 GB
Data Link Protocol: Gigabit Ethernet
Service & Support Type: 2 Years Warranty
Processor
Cache Memory Installed Size: 16 MB
RAM
RAM / Installed Qty: 1
Storage
Hard Drive / Size: 2.5
Hard Drive / Interface Type: SATA 6 Gb/s; SATA 3 Gb/s
Hard Drive / Bays Qty: 2
Expansion
Interfaces & Connections: 4 x RJ45 2.5GbE 802.3bt 90-watt PoE ports, 4 x RJ45 2.5GbE 802.3at 30-watt PoE ports, 8 x RJ45 Gigabit 802.3at 30-watt PoE ports, 2 x 10GbE SFP+ ports
Power
Power / Voltage Required: 100-240V
Dimensions&Miscellaneous
Width: 435.2 Mm
Depth: 327.7 Mm
Height: 44.2 Mm
