About the product
Just like its formidable sibling, the ROG Strix B760-A Gaming WiFi dishes up a vibrant take on the latest Intel platform, with PCIE 5.0, USB 3.2 GEN 2x2, and cyber-inspired ROG motifs emblazoned on a high-contrast backdrop. But this variant features DDR5, bringing even more bandwidth to the table for games and apps."
Technical Specifications
| Dimensions&Miscellaneous | |
| Model: | ROG STRIX B760-A GAMING WIFI |
| Width: | 12 Inch |
| Depth: | 9.6 Inch |
| Primary Information | |
| Mainboard Form Factor: | ATX |
| Mainboard / Chipset Type: | Intel B760 |
| Compatible Processors: | 14th Gen Intel Core, 13th Gen Intel Core & 12th Gen Intel Core, Pentium Gold and Celeron Processors |
| Audio Output: | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| Networking Type: | 1 x Intel 2.5Gb Ethernet |
| Processor | |
| Processor / Max Supported Qty: | 4 |
| Processor / Socket Type: | Socket LGA1700 |
| Memory | |
| RAM / Technology: | DDR5 |
| Data Integrity Check: | Non-ECC |
| RAM / Max Supported Size: | 128 GB |
| Expansion | |
| Expansion Slots Total (Free): | 1 x PCIe 5.0 x16 slot |
| Interfaces & Connections: | 1 x USB 3.2 Gen 2x2 (20G) port (1 x USB Type-C)1 x USB 3.2 Gen 2 (10G) port (1 x Type-A)3 x USB 3.2 Gen 1 (5G) ports (2 x Type-A, 1 x USB Type-C)4 x USB 2.0 ports (4 x Type-A) 1 x DisplayPortFan and Cooling related 1 x 4-pin CPU Fan header1 x 4-pin CPU OPT Fan header1 x 4-pin AIO Pump header4 x 4-pin Chassis Fan headersPower related 1 x 24-pin Main Power connector1 x 8-pin +12V Power connector1 x 4-pin +12V Power connectorStorage related 3 x M.2 slots (Key M)4 x SATA 6Gb/s ports1 x HDMI port1 x Wi-Fi Module1 x Intel 2.5Gb Ethernet port5 x Audio jacks 1 x BIOS FlashBack button |
| Special Feature | |
| COO: | Inquire |
| TAA compliance: | Inquire |
| UNSPSC Code | |
| UNSPSC Code: | 43201513 |
