About the product
TP-Link | Omada Pro gigabit smart switches provide huge upgrade comparing with previous versions. The switches can be managed by TP-Link | Omada Pro SDN Controller, which provides professional and reliable one-step solutions. Integrated L2 and L2+ features such as 802.1Q VLAN, QoS, IGMP Snooping and static routing provide cost-effective networking solutions for small and medium-sized businesses without sacrificing enhanced usability and strong performance.
- Gigabit Ethernet port for ultra-fast network speeds
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- Managed switch provides a reliable foundation for your network
- Management capability provides control over setup and configuration of your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- PoE+ port to receive data and up to 25.5 W of power on a single cable in places where a power outlet is not available
- Quickly and easily set up a wired network with 8 networking ports
Technical Specifications
| Management & Protocols | |
| Manageable | Yes |
| I/O Expansions | |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Total Number of Expansion Slots | 2.0 |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Port/Expansion Slot Details | 2 x Gigabit Ethernet Expansion Slot |
| 8 x Gigabit Ethernet PoE+ | |
| Miscellaneous | |
| Application/Usage | Enterprise |
| Industrial | |
| Network | |
| Business | |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| 1000Base-X | |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Desktop | |
| Height | 1.73" (44 mm) |
| Width | 11.57" (294 mm) |
| Depth | 7.09" (180 mm) |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3z |
| IEEE 802.3u | |
| IEEE 802.3at | |
| IEEE 802.3af | |
| IEEE 802.3ab | |
| IEEE 802.3i | |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | S45008GHP2F |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | S4500-8GHP2F |
| Product Name | Omada Pro 8-Port PoE+ Gigabit Smart Switch with 2 SFP Slots |
| Product Line | Omada Pro |
| Brand Name | TP-Link |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | AC |
| Power Supply | |
| PoE+ | |
| Frequency | 50 Hz |
| 60 Hz | |
| Power Consumption | 174.20 W |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 150 W |
