About the product
This 2.5" hard drive tray lets you add even more flexibility to how you manage your data storage with the SATSASBP425 and SATSASBP125 series backplanes.
Convenient, interchangeable drive tray
This spare drive tray can help you save time in a fast-paced work environment. It's interchangeable with trays from the StarTech.com single-bay backplane (SATSASBP125) and the four-bay backplane (SATSASBP425), giving you an extra tray in addition to the trays you're already using, to create expandable storage or as part of a rotating back-up solution.
Easy compatibility
The drive tray supports both SAS and SATA 2.5" drives, ranging from 5 to 15mm in height. To maximize the performance of your hard drives, the single and quad-bay backplanes support SAS II and SATA III enabling file transfer speeds up to 6 Gbps when paired with a compatible controller.
Vented metal design for durability
The durable aluminum drive tray is designed for long-lasting performance. The venting helps to ensure proper air flow and maximize heat dissipation, to help keep your drives running at optimal temperatures.
The SATSASTRX25 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
More from the Manufacturer
- Swap drives quickly with this drive tray for 2.5" SSD/HDDs
- Interchangeable with the single-bay (SATSASBP125) and quad-bay (SATSASBP425) backplanes
- Compatible with 2.5" SAS or SATA SSDs and HDDs 5-15mm
- Durable aluminum tray with ventilation
- Flammability rating of UL 94-V0
Technical Specifications
| Network & Communication | |
| Wireless LAN | No |
| I/O Expansions | |
| Number of Total Expansion Bays | 1 |
| "Number of 2.5"" Bays" | 1 |
| Interfaces/Ports | |
| Drive Interface | Serial Attached SCSI (SAS) |
| SATA/600 | |
| Technical Information | |
| Number of Hard Drives Supported | 1 |
| Number of Solid State Drive Supported | 1 |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| General Information | |
| Product Type | Drive Bay Adapter |
| Manufacturer Part Number | SATSASTRX25 |
| Manufacturer Website Address | http://www.startech.com |
| Packaged Quantity | 1 |
| Manufacturer | StarTech.com |
| Product Name | 2.5" Hot Swap Hard Drive Tray for SATSASBP125 and SATSASBP425 Series Backplanes |
| Brand Name | StarTech.com |
| Physical Characteristics | |
| Weight (Approximate) | 3.17 oz (90 g) |
| Form Factor | Internal |
| Height | 0.70" (17.78 mm) |
| Width | 2.80" (71.12 mm) |
| Depth | 4.70" (119.38 mm) |
| Cooling Fan | No |
| Product Color | Black |
| Silver | |
| Product Material | Plastic |
| Steel |
