About the product
The 4-port Amer Networks 10/100M Desktop PoE Switch provides a seamless network connection, integrating 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities. Cost saving and flexible with PoE power provision, the SD4P4U provides a PoE power injector function which is able to drive 4 IEEE 802.3af compliant powered devices. The switch also provides a simple, cost-effective, and highly reliable network connection for data as well as power.
- 8+1 port 10/100 Switch with 4 x PoE IEEE802.3af ports & 5 x 10/100Mbps ports including uplink
- Standard IEEE802.3af support
- Wall and deskmount mounting
- Metal Chassis Construction
- Total PoE power budget: 60W
- Supports networking standards IEEE 802.3i, 802.3x, 802.3af, 802.3at
Technical Specifications
| Management & Protocols | |
| Manageable | No |
| Network & Communication | |
| Layer Supported | 2 |
| Power Description | |
| Power Source | Power Adapter |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | China |
| Media & Performance | |
| Network Technology | 10/100Base-TX |
| Ethernet Technology | Fast Ethernet |
| Media Type Supported | Twisted Pair |
| Interfaces/Ports | |
| Modular | No |
| Uplink Port | Yes |
| Stack Port | No |
| Total Number of Network Ports | 9 |
| Port/Expansion Slot Details | 4 x Fast Ethernet Network |
| 5 x Fast Ethernet Uplink | |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | SD4P4U |
| Manufacturer Website Address | http://www.amermounts.com |
| Packaged Quantity | 1 |
| Manufacturer | Amer Networks, Inc |
| Product Model | SD4P4U |
| Product Name | 8+1 Port 10/100 Switch with 4 x PoE Ports and 5 x 10/100 |
| Brand Name | Amer |
| Physical Characteristics | |
| Weight (Approximate) | 2.80 lb (1270.058636 g) |
| Form Factor | Wall Mountable |
| Under Table | |
| Desktop | |
| Length | 8.60" (218.44 mm) |
| Height | 1.10" (27.94 mm) |
| Width | 4.10" (104.14 mm) |
| Product Color | Blue |
| Color Family | Blue |
