PS DIN METAL 240W 48V

Name: PS DIN METAL 240W 48V
Brand: Advantech
SKU: RSC377910
Price: 371.99 CAD
Availability: OutOfStock

$371.99 CAD

~~$416.63 CAD~~ $371.99 CAD

-10% OFF Ask for quote

Shipping calculated at checkout.

Advantech B+B SmartWorx 240W Single Output Industrial Din Rail With PFC Function - DIN Rail - 120 V AC, 230 V AC, 370 V DC Input - 48 V Output - 240 W - 94% Efficiency

VPN:SDR-240-48 SKU:RSC377910 UPC:

High efficiency 91% and low power dissipation
Built-in active PFC function, PF>0.93
Protections: Short circuit / Overload / Over voltage / Over temperature

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

About the product

High efficiency 91% and low power dissipation
Built-in active PFC function, PF>0.93
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
UL 508 (industrial control equipment) approved
EN61000-6-2(EN50082-2) industrial immunity level
100% full load burn-in test

Technical Specifications

Technical Information
Efficiency	94%
Miscellaneous
Country of Origin	Taiwan
Environmentally Friendly	Yes
Environmental Certification	TÜV Rheinland Green Product
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
Physical Characteristics
Form Factor	DIN Rail
Height	4.93" (125.20 mm)
Width	2.48" (63 mm)
Depth	4.47" (113.50 mm)
Power Description
Input Voltage	370 V DC
	120 V AC
	230 V AC
Output Power	240 W
Output Voltage	48 V
Output Current	5 A
Output Voltage Detail	48 V @ 5 A
General Information
Product Type	Proprietary Power Supply
Manufacturer Part Number	SDR24048
Manufacturer Website Address	http://www.advantech.com
Manufacturer	Advantech Co., Ltd
Product Model	SDR-240-48
Product Name	240W Single Output Industrial Din Rail With PFC Function
Product Line	MeanWell
Product Series	SDR-240
Brand Name	B+B SmartWorx
