About the product
Realize More Possibilities with Omada
JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+
TL-SG2210MP
Centralized Cloud Management
Omada SDN Platform Integration
Advanced L2 Features
L2/L3/L4 QoS, ACL, IGMP Snooping and More
Abundant Security Strategies
LAN Area Investment Protection
PoE+ Output
8 PoE+ Ports with Total 150 W Power Budget
Software Defined Networking (SDN) with Cloud Access
Omada's Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network-all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.
- Gigabit Ethernet port for ultra-fast network speeds
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Useful for the multi-tenant unit and multi-business unit with Layer 4 traffic classifiers and bandwidth limit
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
- Quickly and easily set up a wired network with 10 networking ports
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 10 ports
Technical Specifications
| Management & Protocols | |
| Manageable | Yes |
| I/O Expansions | |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Total Number of Expansion Slots | 2.0 |
| Miscellaneous | |
| Application/Usage | Education |
| Retail | |
| Office | |
| Network | |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Total Number of Network Ports | 10 |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE+ |
| 2 x Gigabit Ethernet Expansion Slot | |
| Media & Performance | |
| Network Technology | 1000Base-X |
| 10/100/1000Base-T | |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| Physical Characteristics | |
| Form Factor | Desktop |
| Rack-mountable | |
| Height | 1.70" (43.18 mm) |
| Width | 11.60" (294.64 mm) |
| Depth | 7.10" (180.34 mm) |
| Compatible Rack Unit | 1U |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | SG2210MP |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | TL-SG2210MP |
| Product Name | JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+ |
| Product Line | JetStream |
| Brand Name | TP-Link |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | AC |
| PoE+ | |
| Power Supply | |
| Frequency | 60 Hz |
| 50 Hz | |
| Power Consumption | 173.90 W |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 150 W |
| Network & Communication | |
| Layer Supported | 4 |
| Networking Standards | IEEE 802.1w |
| IEEE 802.3z | |
| IEEE 802.3x | |
| IEEE 802.3u | |
| IEEE 802.3i | |
| IEEE 802.3az | |
| IEEE 802.3at | |
| IEEE 802.3af | |
| IEEE 802.3ad | |
| IEEE 802.3ab | |
| IEEE 802.1x | |
| IEEE 802.1s | |
| IEEE 802.1Q | |
| IEEE 802.1p | |
| IEEE 802.1D |
