About the product
- 4 × 10 Gbps SFP+ Slots
- 24 × 2.5 Gbps RJ45 Ports
- Centralized Management
- Omada App
- Zero-Touch Provisioning
- Ethernet Ring Protection Switching
- Static Routing
- Traffic Separation
Unlock the peak performance of 2.5G Multi-Gig Bandwidth and Devices
- 2.5G WiFi 7/6E/6 APs
- 2.5G Gaming Computer
- 2.5G NAS/Server
- 4K Video
- Network Video Recorder
- Printer
- The desktop installation makes it ideal for deployments outside the wiring closet
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Management capability provides control over setup and configuration of your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Quickly and easily set up a wired network with 24 networking ports
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 24 ports
Technical Specifications
| Management & Protocols | |
| Manageable | Yes |
| Technical Information | |
| Features | Zero-Touch Provisioning (ZTP) |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Total Number of Expansion Slots | 4 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Total Number of Network Ports | 24 |
| Port/Expansion Slot Details | 4 x 10 Gigabit Ethernet Expansion Slot |
| 24 x 2.5 Gigabit Ethernet Network | |
| Media & Performance | |
| Network Technology | 10GBase-X |
| 2.5GBase-T | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| 10 Gigabit Ethernet | |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| Miscellaneous | |
| Application/Usage | Wireless Access Point |
| Server | |
| Network | |
| Printer | |
| Package Contents |
|
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Form Factor | Desktop |
| Rack-mountable | |
| Height | 1.70" (43.18 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 7.10" (180.34 mm) |
| Product Material | Metal |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Power Source | Power Supply |
| Frequency | 60 Hz |
| 50 Hz | |
| Power Consumption | 45.10 W |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3ah |
| IEEE 802.1p | |
| IEEE 802.1Q | |
| IEEE 802.3x | |
| IEEE 802.3ab | |
| IEEE 802.1x | |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | SG3428X-M2 |
| Manufacturer Website Address | http://www.tp-link.com |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Product Model | SG3428X-M2 |
| Product Name | Omada SG3428X-M2 Ethernet Switch |
| Product Line | Omada |
| Brand Name | TP-Link |
