Switches & Hubs

Expected delivery 3 to 7 business days (exceptions applied)

Tp Link

2.5G POE POE PORTS FOR WIFI 7 6E 6 24X 2.5 GBPS PORTS SMASH TH

2.5G POE POE PORTS FOR WIFI 7 6E 6 24X 2.5 GBPS PORTS SMASH TH

Regular price $904.79 CAD
Regular price $1,013.36 CAD Sale price $904.79 CAD
-10% OFF Ask for quote
Shipping calculated at checkout.
Tp Link TP-Link Omada SG3428XPP-M2 - Omada 24-Port 2.5GBASE-T and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++ - Omada 24-Port 2.5GBASE-T and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++ PORT: 16× 2.5G PoE+ Ports, 8× 2.5G PoE++ Ports, 4× 10G SFP+ Slots, RJ45/Micro-USB Console Port SPEC: 802.3bt/at/af, 500 W PoE Power, 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with Omada SDN Controller, Static Routing, OAM, DDM, 802.1Q VLAN, QinQ, STP/R

VPN:SG3428XPP-M2 SKU:253469NDS UPC:840030709739

  • 8× 2.5G PoE++ ports (up to 60 W PoE out per port)
  • 16× 2.5G PoE+ ports (up to 30 W PoE out per port)
  • 4× 10G SFP+ slots

Volume discount available - Ask for quote..

View full details

Recently Viewed

2.5G POE POE PORTS FOR WIFI 7 6E 6 24X 2.5 GBPS PORTS SMASH TH

Product information summary

2.5G POE   POE  PORTS FOR WIFI 7 6E 6  24X 2.5 GBPS PORTS SMASH TH

About the product

TP-Link | Omada L2+ managed switches provide high performance, powerful L2 and L2+ features like static routing, enterprise-level QoS, advanced security strategies and a bundle of ISP features. The 10-gigabit ports ensure high-speed data transfer, and their backward compatility with gigabit products reserves room for network upgrades, therefore guarantees stable and long-term usability. The IP-MAC-Port Binding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-of-Service (DoS) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM function helps facilitate network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link | Omada L2+ 10-gigabit managed switches provide a reliable, secure solution for enterprise, campus and ISP networks.

  • 8× 2.5G PoE++ ports (up to 60 W PoE out per port)
  • 16× 2.5G PoE+ ports (up to 30 W PoE out per port)
  • 4× 10G SFP+ slots
  • 500 W total PoE budget
  • Centralized cloud management via the web or the Omada app
  • Standalone management via web, CLI, SNMP, and RMON
  • Static Routing helps route internal traffic for higher efficiency
  • VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
  • ERPS supports rapid protection and recovery in a ring topology

Technical Specifications

Management & Protocols
ManageableYes
I/O Expansions
Expansion Slot TypeSFP+
Number of SFP+ Slots4
Total Number of Expansion Slots4
Physical Characteristics
Form FactorRack-mountable
Height1.70" (43.18 mm)
Width17.30" (439.42 mm)
Depth13" (330.20 mm)
Compatible Rack Unit1U
Miscellaneous
Application/UsageOffice
Retail
Network
Campus
Enterprise
Package Contents
  • Omada 24-Port 10/100Mbps + 4-Port Gigabit Smart Switch with 24-Port PoE+
  • Quick Installation Guide
  • Rackmount Kit
  • Rubber Feet
Interfaces/Ports
Network (RJ-45)Yes
Uplink PortYes
Total Number of Network Ports24
Port/Expansion Slot Details1 × Micro-USB Console Port
1 × RJ-45 Console Port
24 x 10/100/1000Mbps 2.5Gbps RJ-45 Network Port
4 x 10Gigabit Ethernet SFP+ Expansion Slots
General Information
Product TypeEthernet Switch
Manufacturer Part NumberSG3428XPPM2
Manufacturer Website Addresshttp://www.tp-link.com
ManufacturerTP-LINK Technologies Co., Ltd
Product ModelTL-SG3428XPP-M2
Product NameOmada 24-Port 2.5GBASE-T and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++
Product LineJetStream
Brand NameTP-Link
Power Description
Input Voltage230 V AC
120 V AC
Power SourcePower Supply
Frequency60 Hz
50 Hz
Power Consumption629.10 W
PoE (RJ-45) PortYes
PoE Budget500 W
Media & Performance
Network Technology10GBase-X
10/100/1000Base-T
2.5GBase-T
Maximum Data Transfer Rate1.25 GB/s
Ethernet Technology10 Gigabit Ethernet
2.5 Gigabit Ethernet
Gigabit Ethernet
Media Type SupportedOptical Fiber
Twisted Pair
Network & Communication
Layer Supported2
Networking StandardsIEEE 802.3z
IEEE 802.3x
IEEE 802.3u
IEEE 802.3bz
IEEE 802.3i
IEEE 802.1D
IEEE 802.3bt
IEEE 802.3ah
IEEE 802.3af
IEEE 802.3ae
IEEE 802.3ad
IEEE 802.3ab
IEEE 802.1x
IEEE 802.1w
IEEE 802.1s
IEEE 802.1Q
IEEE 802.1p

Product compare

Product warranty

Standard manufacturer warranty as applicable

Return policy

15 days return in original condition.

Price guarantee

!00% we are always lower than market price.
