About the product
Designed for use with Power over Ethernet (PoE) devices, the SG4P1AT switch provides up to 25.5W of power to 802.3at PoE compatible devices connected to the switch's PoE ports. The Switch allows these devices to draw power from the switch and remove the need for a power adapter. Some devices that may have support for 802.3at are Wireless Access Points, IP Phones, and IP Cameras. The Switch's ports automatically negotiate between 10 BASE-T, 100 BASE-TX, and 1000BASE-T network speeds, as well as between full and half duplex modes, so any port can connect to a Fast Ethernet or Ethernet network. The ports also support Auto MDIX, allowing the automatic detection of a straight-through or cross-over cable, this feature reduces support problems commonly caused by incorrect cable usage.
- 4 x 1 Gigabit PoE Ethernet Ports, 1 x 1 Gigabit Ethernet Port
- Standard IEEE802.3at support
- Metal Chassis Construction
- Wall and Desktop Mounting
Technical Specifications
| Management & Protocols | |
| Manageable | No |
| Network & Communication | |
| Layer Supported | 2 |
| Power Description | |
| Power Source | Power Adapter |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| Ethernet Technology | Gigabit Ethernet |
| Media Type Supported | Twisted Pair |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Interfaces/Ports | |
| Modular | No |
| Uplink Port | Yes |
| Stack Port | No |
| Total Number of Network Ports | 5 |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet Network |
| 1 x Gigabit Ethernet Uplink | |
| General Information | |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | SG4P1AT |
| Manufacturer Website Address | http://www.amermounts.com |
| Packaged Quantity | 1 |
| Manufacturer | Amer Networks, Inc |
| Product Model | SG4P1AT |
| Product Name | 5 Gigabit Desktop Switch with 4 x PoE 802.3at Plus 1 x GIG Uplink |
| Brand Name | Amer |
| Physical Characteristics | |
| Weight (Approximate) | 10.88 oz (308.442812 g) |
| Form Factor | Desktop |
| Under Table | |
| Wall Mountable | |
| Height | 1.10" (27.94 mm) |
| Width | 3.35" (85.09 mm) |
| Depth | 4.65" (118.11 mm) |
| Product Color | Blue |
| Color Family | Blue |
