About the product
Tripp Lite's SMART500RT1UTAA intelligent, line-interactive rack/tower uninterruptible power supply prevents data loss, downtime and equipment damage due to power outages, voltage fluctuations and transient surges. Requires only one rack space (1U) in a 2 or 4 post rack, with included accessories for upright tower placement. Large internal batteries offer 14.6 minutes half load runtime and 3.2 minutes at full load. Maintains regulated 120V nominal output without using battery power during brownouts as low as 90V. 500VA/300 watt power handling capability is compatible with networking, telecom and other sensitive electronic applications. Includes 6 UPS supported outlets with a single outlet load bank that can be individually controlled via software interface to reboot select equipment on demand or shed less significant loads to extend battery runtime for more critical equipment. Includes 1 surge-only outlet for peripherals not requiring battery backup.
Supports simultaneous remote monitoring of UPS and site power conditions via built-in USB and DB9 monitoring ports. Includes PowerAlert UPS monitoring and unattended shutdown software with complete cabling. Built-in accessory slot supports SNMP with optional SNMPWEBCARD adapter. Emergency Power Off (EPO) interface offers option for instantaneous power-off of UPS and connected equipment in the case of fire or emergency situation. Multi-function audible alarms and set of 5 front panel LEDs offer at-a-glance notification of UPS and line power status. Network-grade AC surge suppression protects equipment from damage and performance problems resulting from transient surges and line noise. Attractive all-black color scheme.
Supports simultaneous remote monitoring of UPS and site power conditions via built-in USB and DB9 monitoring ports. Includes PowerAlert UPS monitoring and unattended shutdown software with complete cabling. Built-in accessory slot supports SNMP with optional SNMPWEBCARD adapter. Emergency Power Off (EPO) interface offers option for instantaneous power-off of UPS and connected equipment in the case of fire or emergency situation. Multi-function audible alarms and set of 5 front panel LEDs offer at-a-glance notification of UPS and line power status. Network-grade AC surge suppression protects equipment from damage and performance problems resulting from transient surges and line noise. Attractive all-black color scheme.
- Works adequately in situations where the supply is prone to sags and surges
- Experience higher efficiency with lower energy cost
- Prevent critical data loss by staying powered during a blackout with up to 300 W load capacity
- 500 VA load capacity provides sufficient backup during power failures
- Keep your sensitive devices powered with a backup of up to 3.20 minute at full load
Technical Specifications
| Controls/Indicators | |
| Status Indicators | LED |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Battery Information | |
| Hot Swappable | Yes |
| Backup/Run Time (Half Load) | 14.60 Minute |
| Backup/Run Time (Full Load) | 3.20 Minute |
| Interfaces/Ports | |
| USB | Yes |
| Network (RJ-45) | Yes |
| Modem (RJ-11) | Yes |
| Serial Port | Yes |
| Management | |
| Battery Management | Field-replaceable |
| Alarm | Overload |
| Low Battery | |
| Power Failure | |
| Physical Characteristics | |
| Weight (Approximate) | 17.60 lb (7983.23 g) |
| Form Factor | Rack/Tower |
| Rack Height | 1U |
| Height | 1.70" (43.18 mm) |
| Width | 17.50" (444.50 mm) |
| Depth | 11.80" (299.72 mm) |
| Miscellaneous | |
| Package Contents |
|
| Software Included | PowerAlert unattended shutdown and UPS/Power monitoring |
| Certifications & Standards |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| General Information | |
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | SMART500RT1UTAA |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Manufacturer | Eaton Corporation |
| Product Model | SMART500RT1UTAA |
| Product Name | SmartPro SMART500RT1UTAA 500VA Tower/Rack Mountable UPS |
| Product Line | SmartPro |
| Brand Name | Tripp Lite by Eaton |
| Power Description | |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Input Current | 5.60 A |
| Surge Energy Rating | 567 J |
| Waveform Type | Sine Wave |
| Pulse-width Modulated Sine Wave | |
| Load Capacity (VA) | 500 VA |
| Load Capacity (Watt) | 300 W |
| Technical Information | |
| Dataline Protection | RJ-45 |
| RJ-11 | |
| Emergency Power OFF | Yes |
| Protection Type | Brownout |
| Transient | |
| Surge | |
| Line Noise | |
| EMI / RFI | |
| Plug/Connector Type | NEMA 5-15P |
| Cord Length | 10 ft (3.05 m) |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 7 x NEMA 5-15R |
