About the product
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1920VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-20P input, 6 NEMA 5-15R and 2 NEMA 5-20R outlets. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMTL UPS has a 5-year warranty on the UPS and Lithium-ion battery.
- Works adequately in situations where the supply is prone to sags and surges
- 1.92 kVA load capacity provides sufficient backup during power failures
Technical Specifications
| Management | |
| Network Management | SmartConnect |
| Warranty | |
| Additional Warranty Information | 5 year repair or replace |
| Battery Information | |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Typical Battery Recharge Time | 2 Hour |
| Power Description | |
| Input Voltage | 120 V |
| Output Voltage | 120 V AC |
| Surge Energy Rating | 530 J |
| Waveform Type | Sine Wave |
| Load Capacity (VA) | 1.92 kVA |
| General Information | |
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | SMTL2200RM2UC |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Manufacturer | Schneider Electric SA |
| Product Name | Smart-UPS, Lithium-Ion, 2200VA, 120V with SmartConnect Port |
| Product Line | Smart-UPS |
| Brand Name | APC by Schneider Electric |
| Technical Information | |
| Application/Usage | Network |
| Server | |
| Plug/Connector Type | NEMA 5-20P |
| Cord Length | 8 ft (2.44 m) |
| Receptacle Type | NEMA 5-20P |
| Number of Battery & Surge Outlets | 8 |
| Receptacle Detail | 6 x NEMA 5-15R |
| 2 x NEMA 5-20R | |
| Physical Characteristics | |
| Weight (Approximate) | 70.33 lb (31901.15 g) |
| Rack Height | 2U |
| Height | 3.39" (86 mm) |
| Width | 17.01" (432 mm) |
| Depth | 26.89" (683 mm) |
| Product Color | Silver |
| Black | |
| Color Family | Dual Color |
| Mounting Preference | Lower |
| Miscellaneous | |
| Software Included | Powerchute Serial Edition |
| Certifications & Standards | cULus|ENERGY STAR V2.0 (USA) |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Mercury Free | Yes |
| For Country/Region | United States |
| Product Take Back Program | No |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMTL2200RM2UC_ROHS_DECLARATION&p_FileName=SMTL2200RM2UCKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=552168908&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=552168908&lang=en-us |
| Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612029_EN |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612029_EN |
| Energy Star URL | https://www.energystar.gov/products/uninterruptible_power_supplies |
| REACH free of SVHC | Yes |
| WEEE Statement | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
