About the product
SS3GR5052XP is a member of the Amer SS3GR5000 Series of Layer 3 intelligent. LAN switches desigened for carrier, MAN networks and multi-campus LAN networks. It supports comprehensive QoS,enhanced VLAN functions (VLAN VPN, Voice VLAN, QinQ, N:1 VLAN Translation etc), Ethernet Ring Protection Protocol (G.8032), classified bandwidth control, intelligent security control, OAM (Operations, Administration and Maintenance), manageability functions and Triple-Play services which fulfill the network requirements demanded by carrier network, MAN access and multi-campus LAN networks.
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- Rack mounting enables you to organize wires & secure cables for professional installation
- Can work as layer 3 routing for scalable network design
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Stack port provides an easy and hassle-free way to extend your office network
- Quickly and easily set up a wired network with 50 networking ports
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 50 ports
Technical Specifications
| Management & Protocols | |
| Manageable | Yes |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 2 |
| Total Number of Expansion Slots | 2.0 |
| Interfaces/Ports | |
| Stack Port | Yes |
| Total Number of Network Ports | 50 |
| Port/Expansion Slot Details | 50 x Gigabit Ethernet Network |
| 2 x 10 Gigabit Ethernet Expansion Slot | |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T |
| 1000Base-X | |
| Ethernet Technology | Gigabit Ethernet |
| 10 Gigabit Ethernet | |
| Fast Ethernet | |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| Physical Characteristics | |
| Weight (Approximate) | 16.53 lb (7500 g) |
| Form Factor | Rack-mountable |
| Desktop | |
| Height | 1.72" (43.60 mm) |
| Width | 17.44" (443 mm) |
| Depth | 11.02" (280 mm) |
| Compatible Rack Unit | 1U |
| General Information | |
| Product Type | Layer 3 Switch |
| Manufacturer Part Number | SS3GR5052XP |
| Manufacturer Website Address | http://www.amermounts.com |
| Manufacturer | Amer Networks, Inc |
| Product Model | SS3GR5052XP |
| Product Name | SS3GR5052XP L3 - 10G PoE Access Switch (48*10/100/1000Base-T + 2*GbE (SFP) + 2*1 |
| Product Series | SS3GR5000 |
| Brand Name | Amer |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Power Source | Power Supply |
| Frequency | 50 Hz |
| 60 Hz | |
| Power Consumption | 897 W |
| PoE (RJ-45) Port | Yes |
| Redundant Power Supply Supported | Yes |
| PoE Budget | 740 W |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.1ag |
| IEEE 802.1Q | |
| IEEE 802.1s | |
| IEEE 802.1w | |
| IEEE 802.1x | |
| IEEE 802.3af | |
| IEEE 802.3ah | |
| IEEE 802.1D | |
| IEEE 802.3az | |
| IEEE 802.3at |
