About the product
Features
Optimized for latency-sensitive applications and mixed-use workloads the EV200 hot-swap solid state drive (SSD) utilizes V-NAND technology to deliver exceptional around the clock performance for growing data center demands. The SATA interface enables storage capacity to expand while utilizing the existing IT infrastructure - achieving the optimum price/performance for converged and virtualized architectures.
For use in data centers supporting enterprises that require 24/7 accessibility to cloud services and applications. Designed for read-intensive application workloads where high performance, reliable throughput, data integrity and data loss protection is at the forefront.
Product Spotlight:
- Low total cost of ownership (TCO)
- Proven quality and reliability
- Optimized for data center applications
- Enhanced enterprise endurance with 1.4 Drive Writes Per Day (DWPD)
- Sustained Read/Write IOPS up to 99K/18K
Product Features:
- Built with 3-bit MLC V-NAND Flash technology
- Strong IOPS consistency - low I/O latency and high I/O throughput performance
- Enterprise-grade power-loss protection and power failure protection
- Temperature sensor and monitoring
- Low power consumption
- Enhanced end-to-end data protection
- Innovative flash endurance and data integrity protection via 32-cell vertical NAND architecture
Specialized for the following workloads:
- Demanding Quality of Service (QoS), latency-sensitive applications and databases
- IaaS, PaaS, and SaaS Infrastructure
- NoSQL performance acceleration
- DBaas, MySQL, PostgreSQL transaction processing
- OpenStack cloud computing platforms
- Software-defined storage upgrades
- E-Commerce, micropayments
- Have data stored faster with SATA/600 interface that optimizes burst performance
- 256-bit encryption protects your PC from hackers and thieves by encoding all your data
- The high-read speed of 550 MB/s maximizes system performance and saves time while you are doing complex tasks
- With the high-write speed of 320 MB/s, get a quick response when updating or transferring files
- Provides sufficient storage capacity of 240 GB for your computer
Technical Specifications
| Network & Communication | |
| Wireless LAN | No |
| Power Description | |
| Operating Power Consumption | 4.10 W |
| Interfaces/Ports | |
| Drive Interface | SATA |
| Drive Interface Standard | SATA/600 |
| Technical Information | |
| Storage Capacity | 240 GB |
| Encryption Standard | 256-bit |
| Physical Characteristics | |
| Hot Swappable | Yes |
| Drive Type | Internal |
| Form Factor | 3.5" |
| Drive Performance | |
| Maximum Read Transfer Rate | 550 MB/s |
| Maximum Write Transfer Rate | 320 MB/s |
| Endurance (DWPD) | 1.3 |
| Endurance (TBW) | 341 TB |
| Endurance Type | Mixed Use |
| Miscellaneous | |
| Compatibility | Dell Server's:
|
| Device Supported | Server |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| General Information | |
| Product Type | Solid State Drive |
| Manufacturer Part Number | SSDEV20KG240-AX |
| Manufacturer Website Address | http://search.axiomupgrades.com |
| Manufacturer | Axiom Memory Solutions |
| Product Model | EV200 |
| Product Name | 3.5" Hot-Swap Enterprise Value EV200 SSD |
| Brand Name | Axiom |
