About the product
The ST121SHD50 HDMI® over Cat5e/Cat6 Video Extender kit lets you extend HDMI video and audio by up to 165 feet (50 Meters) over dual Cat5e cables or dual Cat6 cables.For added versatility the kit features Power Over Cable andonly requires asingle power adapter that can be connected to either the Transmitter or Receiver. With support for High-Definition resolutions of up to 1920x1080 / 1080p and the accompanying digital audio, this cost-effective HD extender can easily be installed using new or existing Ethernet infrastructure wiring. For a convenient plug-and-play installation, the HDMI extender features built-in EDID monitor emulation
which ensures native resolution and maximum compatibility with your display or projector. For added flexibility and convenience, HDMI cables up to 32ft (10m) can be connected to both the local and remote units, which lets you extend your HDMI signal to even further distances. The HDMI extender kit offers a point-to-point digital signage solution right out of the box, including both local transmitter and remote receiver units, along with optional hardware that lets you mount the units as needed.Plus, withPowerOverCable, you can easily extend anHDMI signal inareas where access to power outlets is limited. This product is TAA compliant and backed by a Startech.com 2-year warranty with free lifetime technical support. More from the Manufacturer More from the ManufacturerPower Over Cable allows a single power source to operate the Transmitter and ReceiverSupports Cat5e or Cat6 Ethernet cabling (50m)No software/drivers requiredSupports HD resolutions up to 1080p (1920x1080)Includes transmitter (local) and receiver (remote) units
Technical Specifications
| Media & Performance | |
| Twisted Pair Cable Standard | Category 6 |
| Media Type Supported | Twisted Pair |
| Power Description | |
| Input Voltage | 110 V AC |
| 220 V AC | |
| Video | |
| Graphics Modes | Full HD |
| Maximum Video Resolution | 1920 x 1080 |
| Technical Information | |
| Connectivity Technology | Wired |
| Daisy Chain | No |
| Maximum Operating Distance | 164.04 ft (50000 mm) |
| Number of Output Devices Supported | 1 |
| Number of Input Devices Supported | 1 |
| Interfaces/Ports | |
| Number of Network (RJ-45) Ports | 4 |
| Network (RJ-45) | Yes |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 1 |
| HDMI In | Yes |
| HDMI Out | Yes |
| General Information | |
| Product Type | Video Extender Transmitter/Receiver |
| Manufacturer Part Number | ST121SHD50 |
| Manufacturer Website Address | http://www.startech.com |
| Packaged Quantity | 1 Kit |
| Manufacturer | StarTech.com |
| Product Name | HDMI Over CAT5/CAT6 Extender with Power Over Cable - 165 ft (50m) |
| Brand Name | StarTech.com |
| Miscellaneous | |
| Package Contents |
|
| Certifications & Standards |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Restriction of Hazardous Substances (RoHS) | |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Length | 3.10" (78.74 mm) |
| Transmitter Height | 0.80" (20.32 mm) |
| Transmitter Width | 2" (50.80 mm) |
| Transmitter Depth | 3.10" (78.74 mm) |
| Receiver Height | 0.80" (20.32 mm) |
| Receiver Width | 2" (50.80 mm) |
| Receiver Depth | 3.10" (78.74 mm) |
| Transmitter Weight (Approximate) | 11.08 oz (314 g) |
| Receiver Weight (Approximate) | 11.08 oz (314 g) |
| Product Color | Black |
| Color Family | Black |
| Product Material | Aluminum |
