StarTech.com HDMI over CAT6 Extender with 4
StarTech.com HDMI over CAT6 Extender with 4
VPN:ST121USBHD SKU:CBAV8443F CPU:65030862363
Crystal-clear picture quality, with support for uncompressed 1920x1200 or 1080p HD video extensionEasy remote peripheral integration, with a built-in 4-port USB hubTidy, professional installation using the included mounting hardware
Couldn't load pickup availability
Volume discount available - Ask for quote..
View full details




Recently Viewed
StarTech.com HDMI over CAT6 Extender with 4
Product information summary

About the product
This HDMI® extender kit lets you transmit yourHD video sourceto your remote HDMIdisplay at a distance of up to 165 ft. (50 m) away. 1080p video can be extended 131 ft. (40 m) using shielded CAT 6 cabling. The extender features a built-in4-port USB 2.0 hub that also lets you connect four remote USB peripheral devices at your display location. Crystal-clear picture quality Using this HDMI extender, you can maintain the quality ofyour high-definition video signal along with theaccompanying 7.1 digital audio, even at 165 feet away from your source device. The extender supportsresolutions up to 1920x1200 or 1080p -perfectfor dazzling your audience in remote digital-signage applications in hospitalsor at shopping centers. Hassle-free remote USB integration The built-in 4-port USB 2.0 hub lets you remotely connect
access or control up to four USB devices located at your remote display -great forflash drives, printers, scanners, external hard drives andI/O devices.Remote USB extension also enables you to remotelycontrol your sourcedevice, which is idealfor adding touchscreen interfaces at your display in market or POS kiosks. Easy installation and setup For hassle-freesetupthe HDMI extender offerseasy plug-and-play installation with noadditional software or drivers required. Plus, the extender passes theEDID information included inyour HDMIsignal,and automatically adjusts video equalizationensuring you won't have to configure it manually. Mounting hardware is also included, for a tidy and professional installation. Note: To maximize performance this extender requires shielded CAT6 cable. When using unshielded CAT6 cable the maximum distance is reduced to 30m. When using CAT5 cable the maximum distance is reduced to 15m. The ST121USBHD is TAA compliant and backed by a 2-year StarTech.com warranty with free lifetime technical support. More from the Manufacturer More from the ManufacturerCrystal-clear picture quality, with support for uncompressed 1920x1200 or 1080p HD video extensionEasy remote peripheral integration, with a built-in 4-port USB hubTidy, professional installation using the included mounting hardwareExtends HDMI video and four USB peripheral devices up to 165 ftSupports CAT5e and CAT6 Ethernet cableHDMI transmitter and receiver included
Technical Specifications
Media & Performance | |
Twisted Pair Cable Standard | Category 6 |
Media Type Supported | Twisted Pair |
Video | |
Graphics Modes | WUXGA |
Maximum Video Resolution | 1920 x 1200 |
Miscellaneous | |
Package Contents |
|
Country of Origin | Taiwan |
Environmentally Friendly | Yes |
TAA Compliant | Yes |
Technical Information | |
Connectivity Technology | Wired |
Maximum Operating Distance | 260 ft (79248 mm) |
Number of Output Devices Supported | 1 |
Number of Input Devices Supported | 1 |
General Information | |
Product Type | Video Extender Transmitter/Receiver |
Manufacturer Part Number | ST121USBHD |
Manufacturer Website Address | http://www.startech.com |
Packaged Quantity | 1 Kit |
Manufacturer | StarTech.com |
Product Name | HDMI over CAT6 Extender with 4-port USB Hub - 165 ft (50m) - 1080p |
Brand Name | StarTech.com |
Physical Characteristics | |
Transmitter Height | 0.80" (20.32 mm) |
Transmitter Width | 3.20" (81.28 mm) |
Transmitter Depth | 3.20" (81.28 mm) |
Receiver Height | 0.80" (20.32 mm) |
Receiver Width | 3.20" (81.28 mm) |
Receiver Depth | 3.20" (81.28 mm) |
Transmitter Weight (Approximate) | 1.01 lb (460 g) |
Receiver Weight (Approximate) | 1.01 lb (460 g) |
Interfaces/Ports | |
USB | Yes |
Number of Network (RJ-45) Ports | 4 |
Network (RJ-45) | Yes |
Number of USB Ports | 5 |
Serial Port | Yes |
Number of HDMI Inputs | 1 |
Number of HDMI Outputs | 1 |
HDMI In | Yes |
HDMI Out | Yes |
