StarTech.com 4K HDMI over IP Receiver for ST12MHDLAN4K
StarTech.com 4K HDMI over IP Receiver for ST12MHDLAN4K
VPN:ST12MHDLAN4R SKU:CBAV9049F CPU:65030868969
Versatile video distribution with support for large multi-display presentations, video walls, video switching and point-to-point extensionAstonishing picture quality over IP with support for 4K at 30Hz resolutionFree mobile app makes it easy to manage switching video wall control (iOS / Android / Chrome browser)
Couldn't load pickup availability
Volume discount available - Ask for quote..
View full details



Recently Viewed
StarTech.com 4K HDMI over IP Receiver for ST12MHDLAN4K
Product information summary

About the product
This 4K HDMI® over IP receiver works with the 4K HDMI over IP Extender Kit (sold separately) and lets you extend a 4K HDMI signal, as well as RS-232 peripheral device connections, over your network. You can use additional receivers (sold separately) to distribute the HDMI signal to multiple locations
each with 4K support, and combine your remote displays to create a video wall. The IP receiver also features RS-232 extension which enables you to add a remote serial operated device at your video source or each remote display. This HDMI over IP extender is the perfect solution for combining a serial-operated touchscreen with your display or video wall, to create interactive digital signage presentations. Extended scalability You can add multiple receivers to your HDMI over IP extender kit to create a point-to-multipoint setup or video wall. In these configurations, you can also add additional sources (transmitters) with even more displays (receivers) over your Gigabit Ethernet switch with IGMP. For further scalability, you can combine up to 16 total (transmitters) and as many receivers (displays) as your network bandwidth can support. The extender also features a separate 3.5 mm audio source that enables you to switch between the native HDMI audio and a separate 3.5 mm audio source, so you can distribute a single audio source to multiple remote locations over IP (also requires a Gigabit Ethernet switch with IGMP). Ultra HD 4K resolution at 30Hz This HDMI over IP kit uses H.264 compression to deliver astonishing 4K UHD video to your remote 4K displays over an IP connection. With support for 4K, you can achieve an output resolution of up to 3840 x 2160p at 30Hz, which enables you to extend a 4K video source to multiple remote locations -- perfect for digital signage or entertainment video distribution throughout large buildings such as schools, hospitals, shopping centers or areas. The extender is backward compatible with lower resolutions such as 1080p or 720p, making it great for lower resolution applications while future-proofing your infrastructure for 4K implementation. Manage your video distribution from your mobile device This HDMI distribution kit features an easy-to-use video control software app that helps you manage your IP video distribution. The app is simple to set up, with automatic hardware detection, and it lets you switch video sources for each remote display. You can also create and manage a video wall, for an impressive digital signage presentation that's sure to catch your audience's attention. The software is available on iOS for your iPhone or iPad, and Android™ for your smartphone or tablet. More from the Manufacturer More from the ManufacturerVersatile video distribution with support for large multi-display presentations, video walls, video switching and point-to-point extensionAstonishing picture quality over IP with support for 4K at 30Hz resolutionFree mobile app makes it easy to manage switching video wall control (iOS / Android / Chrome browser)Tidy, professional installation using the included mounting hardwareConnect using a Gigabit LAN networkEasy point-to-point or point-to-multipoint setupExtend HDMI using existing network infrastructure
Technical Specifications
Media & Performance | |
Twisted Pair Cable Standard | Category 5e |
Media Type Supported | Twisted Pair |
Video | |
Graphics Modes | 4K |
Maximum Video Resolution | 3840 x 2160 |
Technical Information | |
Connectivity Technology | Wired |
Maximum Operating Distance | 328.08 ft (100000 mm) |
Number of Output Devices Supported | 1 |
Interfaces/Ports | |
Number of Network (RJ-45) Ports | 1 |
Network (RJ-45) | Yes |
Number of HDMI Outputs | 1 |
HDMI Out | Yes |
Miscellaneous | |
Package Contents |
|
Environmentally Friendly | Yes |
TAA Compliant | Yes |
Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
Waste Electrical and Electronic Equipment Directive (WEEE) | |
Restriction of Hazardous Substances (RoHS) | |
General Information | |
Product Type | Video Extender Receiver |
Manufacturer Part Number | ST12MHDLAN4R |
Manufacturer Website Address | http://www.startech.com |
Packaged Quantity | 1 Each |
Manufacturer | StarTech.com |
Product Name | 4K HDMI over IP Receiver for ST12MHDLAN4K |
Brand Name | StarTech.com |
Physical Characteristics | |
Form Factor | Rack-mountable |
Receiver Height | 1.20" (30.48 mm) |
Receiver Width | 4.60" (116.84 mm) |
Receiver Depth | 5.20" (132.08 mm) |
Receiver Weight (Approximate) | 1.31 lb (594 g) |
Product Color | Black |
Color Family | Black |
