About the product
This4-Port USB 3.0 HDMI® KVM switch lets you control four HDMIcomputers with a single monitor, keyboardand mouse. The KVM also features 3.5 mm audio and abuilt-in 3-port USB 3.0 hub.
Convenient and cost-effective USB 3.0 peripheral sharing
This KVM switch offers a built-in3-port USB 3.0 hub that's separate from your HID keyboard and mouse, so you can share USB peripheral devices between each connectedcomputer and avoid the expense of separate equipment.The USB 3.0hub automatically switches your connected USB devices to the selected computer, saving you the hassle ofdisconnectingand reconnecting peripherals.
With support for USB 3.0, you can achieve datatransferrates up to 5Gbps, toensureflawless performance for your USB peripherals - great for quickly transferring data to external USB 3.0 drives.
HD picture quality
Offering support for high-definition 1080p resolutions,this 4-port HDMI KVM switch has the ability to drive HDMI displayswith crystal clarity, making it ideal for graphical applications that require 1920 x 1080 video resolutions.
Complete multimedia control
The KVM switch features auxiliary 3.5 mm audio ports thatenableyou to share independent analog audio, from each of your connected computers,with yourdesktop speaker set. Independent audio,along with 1080pHDMIvideo, givesyou full multimediacontrol between different computers, making this KVM perfect for creative professional applications such as video and sound design orediting.
The SV431HDU3A2 is TAA compliant and backed by a StarTech.com 2-year warranty with free lifetime technical support.
Rackmount your KVM switch
If you'd like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket(sold separately) that turns this KVM into a rackmountable KVM.
More from the Manufacturer
- Easily share peripheral devices with built-in USB 3.0 hub
- High definition video quality with support for resolutions up to 1080p
- Full multimedia control with separate 3.5 mm auxiliary support
- No software or drivers required
- Independent HID keyboard and mouse ports
Technical Specifications
| Video | |
| Maximum Video Resolution | 1920 x 1080 |
| Technical Information | |
| Number of Computers Supported | 4 |
| Number of Local Users Supported | 1 |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Input Voltage Range | 100V AC to 240V AC |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| Number of HDMI Ports | 5 |
| Number of USB Ports | 11 |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| General Information | |
| Product Type | KVM Switchbox |
| Manufacturer Part Number | SV431HDU3A2 |
| Manufacturer Website Address | http://www.startech.com |
| Packaged Quantity | 1 Each |
| Manufacturer | StarTech.com |
| Product Name | 4-Port HDMI KVM Switch - USB 3.0 - 1080p |
| Brand Name | StarTech.com |
| Physical Characteristics | |
| Weight (Approximate) | 2.43 lb (1100 g) |
| Form Factor | Desktop |
| Rack-mountable | |
| Rack Height | 1U |
| Height | 1.70" (43.18 mm) |
| Width | 5.10" (129.54 mm) |
| Depth | 8.70" (220.98 mm) |
