Power equipment UPS

Expected delivery 3 to 7 business days (exceptions applied)

Eaton

Eaton Power-Sure 800 T800F-05000 Line Conditioner - AC Surge, AC Noise

Eaton Power-Sure 800 T800F-05000 Line Conditioner - AC Surge, AC Noise

Regular price $7,874.58 CAD
Regular price $8,819.53 CAD Sale price $7,874.58 CAD
-10% OFF Ask for quote
Shipping calculated at checkout.
Eaton Power-Sure 800 T800F-05000 Line Conditioner - AC Surge, AC Noise, Harmonics protection

VPN:T800F-05000 SKU:RSC100346 UPC:

Please see below description

Volume discount available - Ask for quote..

View full details

Recently Viewed

Eaton Power-Sure 800 T800F-05000 Line Conditioner - AC Surge, AC Noise

Product information summary

Eaton Power-Sure 800 T800F-05000 Line Conditioner - AC Surge, AC Noise

About the product

Every facet of our daily life is being automated by faster microprocessors and microprocessor-based equipment which require steady continuous power. As market pressures force the deregulation of the electrical industry, utility companies have less and less control over the quality of power supplied to sensitive electronic equipment. In data processing and medical applications, the effects of unreliable power can be translated into incorrect data, lost memory, premature component failure, mixed and garbled data and inaccurate diagnostics. Power conditioning alleviates these problems. For this reason, the Power-Sure 800 was designed using a special high "K-Factor" transformer capable of handling these harmonics without overheating. The Power-Sure 800 has one of the highest "K-Factors" in the industry. Additionally, the Power-Sure 800 virtually eliminates any transient harmonics being reflected back onto the power lines, thus preventing damage to building wiring.

Technical Specifications

Miscellaneous
Additional Information
  • VA Rating: 5000VA
  • Watt Rating: 5000W
  • AC 120/208/240/480 V - 5 KW
  • Line Regulation: +/- 2% VOut for +10% to -20% V In at 100% Load
  • Load Regulation: +/-3% for 0% to 100% load
  • Immunity to Distortion: @ 40% THD V In, 5% Max THD VOut
  • Ride-through Capability: 1 cycle
  • Voltage Recovery: 2 cycles to 95%, 3 cycles to 100%
  • K-Factor: K-30 Rated
  • Power Factor Correction: Input of 0.95 typical
  • Harmonic Attenuation: -23dB for load reflected harmonics
  • Galvanic Isolation: NEC 250-5d, 0.001 pf
  • Surge Protection: UL 1449 Rating 330 V, ANSI/IEEE 62.41-Cat B3
  • Common Mode Noise Attenuation: 140 dB
  • Transverse Mode Noise Attenuation: 120 dB
  • Reliability: 200,000 hours (MTBF)
  • Audible Noise: 52dB to 56dB measured at 1 meter, A Scale
  • Efficiency: Approx. 92% at full load
Certifications & Standards

Safety: Underwriters Laboratories UL 1012 - UL 544 - cUL

Country of OriginUnited States
Technical Information
Protection TypeAC Noise
AC Surge
Harmonics
Physical Characteristics
Weight (Approximate)184.61 kg
Height28.50" (723.90 mm)
Width20" (508 mm)
Depth23" (584.20 mm)
General Information
Product TypeLine Conditioner
Manufacturer Part NumberT800F05000
Manufacturer Website Addresshttp://www.eaton.com/EatonCom/Markets/NorthAmerica
ManufacturerEaton Corporation
Product ModelT800F-05000
Product NamePower-Sure 800 T800F-05000 Line Conditioner
Product LinePower-Sure
Brand NameEaton
