Eaton Power-Sure 800 Line Conditioner - Lightning, AC Surge, Harmonics

Eaton Power-Sure 800 Line Conditioner - Lightning, AC Surge, Harmonics

Regular price $9,534.23 CAD
Regular price $10,678.34 CAD Sale price $9,534.23 CAD
-10% OFF Ask for quote
Shipping calculated at checkout.
Eaton Power-Sure 800 Line Conditioner - Lightning, AC Surge, Harmonics, AC Noise protection - Hardwired - 208 V AC, 240 V AC, 480 V AC Input - 8 kVA - 8 kW

VPN:T800F-08000 SKU:RSC841108 UPC:

Please see below description

Volume discount available - Ask for quote..

View full details

Recently Viewed

Eaton Power-Sure 800 Line Conditioner - Lightning, AC Surge, Harmonics

Product information summary

Eaton Power-Sure 800 Line Conditioner - Lightning, AC Surge, Harmonics

About the product

Every facet of our daily life is being automated by faster microprocessors and microprocessor-based equipment which require steady continuous power. As market pressures force the deregulation of the electrical industry, utility companies have less and less control over the quality of power supplied to sensitive electronic equipment. In industry, the effects of unreliable power can be seen in the erroneous motion of computer-controlled milling machines, causing irreparable damage to expensive manufacturing equipment or finished products. Additionally, poor power quality can cause motor driven equipment to operate inefficiently and overheat, causing premature failure. In data processing and medical applications, the effects of unreliable power can be translated into incorrect data, lost memory, premature component failure, mixed and garbled data and inaccurate diagnostics. Power conditioning alleviates these problems.

Technical Specifications

Miscellaneous
Additional Information
  • Line Regulation: +/- 2% Vout for +10% to -20% Vin at 100% Load
  • Load Regulation: +/-3% for 0% to 100% load
  • Immunity to Distortion: @40% THD Vin, 5% Max THD Vout
  • Ride-through Capability: 1 cycle
  • Voltage Recovery: 2 cycles to 95%, 3 cycles to 100%
  • K-Factor: K-30 Rated
  • Power Factor Correction: Input of 0.95 typical
  • Harmonic Attenuation: -23dB for load reflected harmonics
  • Galvanic Isolation: NEC 250-5d, 0.001 pf
  • Surge Protection: UL 1449 Rating 330v; ANSI/IEEE C62.41-Cat B3
  • Common Mode Noise Attenuation: 140 dB
  • Transverse Mode Noise Attenuation: 120 dB
  • Reliability: 200,000 hours (MTBF)
  • Audible Noise: 1 meter A scale, 52dB to 56dB
  • Efficiency: Approx. 92% at full load
Physical Characteristics
Weight (Approximate)210.92 kg
Height28.50" (723.90 mm)
Width23" (584.20 mm)
Depth20" (508 mm)
Technical Information
Protection TypeAC Noise
Lightning
Harmonics
AC Surge
Plug/Connector TypeHardwired
Receptacle TypeHardwired
Power Description
Input Voltage480 V AC
240 V AC
208 V AC
Output Voltage240 V AC
Maximum Frequency60 Hz
Load Capacity (VA)8 kW
Load Capacity (Watt)8 kW
General Information
Product TypeLine Conditioner
Manufacturer Part NumberT800F08000
Manufacturer Website Addresshttp://www.eaton.com/EatonCom/Markets/NorthAmerica
ManufacturerEaton Corporation
Product ModelT800F-08000
Product NamePower-Sure 800 Line Conditioner
Product LinePower-Sure
Brand NameEaton
