Eaton Power-Sure 800 Power Conditioner - Harmonics, AC Surge, AC Noise

Name: Eaton Power-Sure 800 Power Conditioner - Harmonics, AC Surge, AC Noise
Brand: Eaton
SKU: RSC611514
Price: 2009.83 CAD
Availability: OutOfStock

$2,009.83 CAD

~~$2,251.01 CAD~~ $2,009.83 CAD

-10% OFF Ask for quote

Shipping calculated at checkout.

Eaton Power-Sure 800 Power Conditioner - Harmonics, AC Surge, AC Noise protection120 V AC, 208 V AC, 240 V AC, 480 V AC Input - 750 VA

VPN:T800P-00750 SKU:RSC611514 UPC:

Please see below description

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

Eaton Power-Sure 800 Power Conditioner - Harmonics, AC Surge, AC Noise

About the product

Power-Sure 800 power conditioners provide high quality power with inherent surge protection, noise and bi-directional harmonic filtering, as well as superior isolation. Power-Sure 800 wall/panel mounted industrial model, and provide an excellent solution for any application with noisy or poor power quality.

Technical Specifications

Miscellaneous
Additional Information	Watt Rating: 750 Line Regulation: +/- 2% Vout for +10% to -20% Vin at 100% Load Load Regulation: +/-3% for 0% to 100% load Immunity to Distortion: @ 40% THD Vin, 5% Max THD Vout Voltage Recovery: 2 cycles to 95%, 3 cycles to 100% K-Factor: K-30 Rated Power Factor Correction: Input of 0.95 typical Galvanic Isolation: NEC 250-5d, 0.001 pf Surge Protection: UL 1449 Rating 330 V; ANSI/IEEE 62.41-Cat B3 Common Mode Noise Attenuation: 140 dB Transverse Mode Noise Attenuation: 120 dB
Compatibility	Data centers Industrial facilities Medical applications Process control Sensitive electronic equipment Instrumentation Robotic control
Certifications & Standards	UL1012 UL544 cUL
Technical Information
Protection Type	AC Surge
	AC Noise
	Harmonics
Physical Characteristics
Weight (Approximate)	27.22 kg
Height	10" (254 mm)
Width	9" (228.60 mm)
Depth	14" (355.60 mm)
Power Description
Input Voltage	208 V AC
	240 V AC
	480 V AC
	120 V AC
Load Capacity (VA)	750 W
General Information
Product Type	Line Conditioner
Manufacturer Part Number	T800P00750
Manufacturer Website Address	http://www.eaton.com/EatonCom/Markets/NorthAmerica
Manufacturer	Eaton Corporation
Product Name	Power-Sure 800 Power Conditioner
Product Line	Power-Sure
Brand Name	Eaton
