About the product
TRENDnet's 6-Port Unmanaged Multi-Gig Switch Features:
- 4 x 2.5GBASE-T ports
- 2 x 10G SFP+ ports
- IEEE 802.3bz (2.5G) compliant
- IEEE 802.3ae (SFP+) compliant
- Backwards compatible with 100/1000BASE-T devices
- 60Gbps switching capacity
- Compact fanless design eliminates noise
- Wall mountable for installation flexibility
- NDAA / TAA compliant (U.S. and Canada only)
- Lifetime Warranty
TRENDnet's 6-Port Unmanaged Multi-Gig Switch Specifications:
- Standards:
- IEEE 802.3ab
- IEEE 802.3ae
- IEEE 802.3an
- IEEE 802.3bz
- IEEE 802.1x
- Device Interface:
- 4 x 2.5G ports (1Gbps/2.5Gbps)
- 2 x 10G SFP+ ports (1Gbps/10Gbps)
- LED indicators
- Data Transfer Rate:
- Gigabit Ethernet: 2000Mbps (full duplex)
- 2.5G Ethernet: 5Gbps (full duplex)
- 10G SFP+: 20Gbps (full duplex)
- Performance:
- Switch fabric: 60Gbps
- RAM buffer: 1MB
- MAC address table: 4K entries
- Jumbo frames: 12KB
- Forwarding mode: Store and forward
- Forwarding rate: 44.64Mpps (64-byte packet size)
- Power:
- Input: 90 – 264V AC, 47/63 Hz
- Output: 12V, 1A
- Max. consumption: 5.86W
- MTBF: 627,723 hours @40°
- Fan / Acoustics: Fanless
- Operating Temperature: 0° – 40° C (32° – 104° F)
- Operating Humidity: Max. 90% non-condensing
- Dimensions: 160 x 110 x 26mm (6.2 x 4.3 x 1 in.)
- Weight: 0.4 kg (1 lbs.)
- Certifications:
- CE
- FCC
- LVD
- Warranty: Lifetime Warranty
Technical Specifications
TRENDnet's 6-Port Unmanaged Multi-Gig Switch Features:
- 4 x 2.5GBASE-T ports
- 2 x 10G SFP+ ports
- IEEE 802.3bz (2.5G) compliant
- IEEE 802.3ae (SFP+) compliant
- Backwards compatible with 100/1000BASE-T devices
- 60Gbps switching capacity
- Compact fanless design eliminates noise
- Wall mountable for installation flexibility
- NDAA / TAA compliant (U.S. and Canada only)
- Lifetime Warranty
TRENDnet's 6-Port Unmanaged Multi-Gig Switch Specifications:
- Standards:
- IEEE 802.3ab
- IEEE 802.3ae
- IEEE 802.3an
- IEEE 802.3bz
- IEEE 802.1x
- Device Interface:
- 4 x 2.5G ports (1Gbps/2.5Gbps)
- 2 x 10G SFP+ ports (1Gbps/10Gbps)
- LED indicators
- Data Transfer Rate:
- Gigabit Ethernet: 2000Mbps (full duplex)
- 2.5G Ethernet: 5Gbps (full duplex)
- 10G SFP+: 20Gbps (full duplex)
- Performance:
- Switch fabric: 60Gbps
- RAM buffer: 1MB
- MAC address table: 4K entries
- Jumbo frames: 12KB
- Forwarding mode: Store and forward
- Forwarding rate: 44.64Mpps (64-byte packet size)
- Power:
- Input: 90 – 264V AC, 47/63 Hz
- Output: 12V, 1A
- Max. consumption: 5.86W
- MTBF: 627,723 hours @40°
- Fan / Acoustics: Fanless
- Operating Temperature: 0° – 40° C (32° – 104° F)
- Operating Humidity: Max. 90% non-condensing
- Dimensions: 160 x 110 x 26mm (6.2 x 4.3 x 1 in.)
- Weight: 0.4 kg (1 lbs.)
- Certifications:
- CE
- FCC
- LVD
- Warranty: Lifetime Warranty
