About the product
This 10-Port Industrial Gigabit PoE+ Wall-Mounted Front Access Switch from Trendnet is ideal for IP surveillance, IoT, and automation network applications for home or business.
The switches provide easy front access to ports and power interfaces, and the flat compact size makes them a good fit for installations where space is limited.
Each device features a gigabit PoE+ ports for connecting devices, such as wireless access points, IP cameras, and IoT appliances, and is equipped with an IP30 rated metal enclosure designed to withstand a high degree of vibration and shock while operating within a wide temperature range of -40° – 75° C, ensuring operation in industrial environments.
TI-PG102F features:
- 8 x Gigabit PoE+ ports
- 2 x Gigabit SFP slots
- 240W PoE power budget
- 20Gbps switching capacity
- Forwarding rate: 14.88Mpps (64-byte packet size)
- Supports jumbo frames up to 10KB
- Hardened IP30 rated metal housing
- Includes DIN-Rail Bracket and magnetic wall mount kit
- Operating temperature range of -40° – 75° C (-40° – 167° F)
- Redundant power inputs with overload current protection
- Alarm relay triggered by power failure
- Power supply sold separately
Technical Specifications
This 10-Port Industrial Gigabit PoE+ Wall-Mounted Front Access Switch from Trendnet is ideal for IP surveillance, IoT, and automation network applications for home or business.
The switches provide easy front access to ports and power interfaces, and the flat compact size makes them a good fit for installations where space is limited.
Each device features a gigabit PoE+ ports for connecting devices, such as wireless access points, IP cameras, and IoT appliances, and is equipped with an IP30 rated metal enclosure designed to withstand a high degree of vibration and shock while operating within a wide temperature range of -40° – 75° C, ensuring operation in industrial environments.
TI-PG102F features:
- 8 x Gigabit PoE+ ports
- 2 x Gigabit SFP slots
- 240W PoE power budget
- 20Gbps switching capacity
- Forwarding rate: 14.88Mpps (64-byte packet size)
- Supports jumbo frames up to 10KB
- Hardened IP30 rated metal housing
- Includes DIN-Rail Bracket and magnetic wall mount kit
- Operating temperature range of -40° – 75° C (-40° – 167° F)
- Redundant power inputs with overload current protection
- Alarm relay triggered by power failure
- Power supply sold separately
